# Brink Security Review (engagement 2)
# Spearbit
Spearbit is a decentralized network of expert Web3 security engineers. Together, we help secure the Web3 ecosystem. We offer security reviews and related services to Web3 projects. Our network has experience at every part of the stack, including protocol design, smart contracts, and the Solidity compiler itself. Spearbit brings in untapped security talent: expert freelance auditors want flexibility to work on interesting projects together. Learn more about us at https://spearbit.com.
# Introduction
The Brink protocol is designed for automating conditional orders on EVM compatible chains. For an introduction to the basic mechanics, one can consult the report from Spearbit's first security review of Brink. This follow up specialized review by Spearbit focussed on a unique extension of "[EIP-1167: Minimal Proxy Contract](https://eips.ethereum.org/EIPS/eip-1167)".
The Brink protocol designed a gas efficient proxy implementation, based on EIP-1167 that also stores the address of the owner in the proxy. Details can be found in the section: ["custom proxy code"](#custom-proxy-code). In short, the address of the owner is appended at the end of the runtime code, and read using a `extcodecopy` of the relevant bytes in code; let's call this the *data section*.
The focus of the security review was on the following:
1. The correctness of the EIP-1167 extension, i.e., the account proxy, as well as the `NotOwner` check.
2. Can the data section of the code be executable? That is, can the execution ever reach anywhere in the final `20-byte-address`? Depending on the address, this possibility can make proxy accounts vulnerable.
3. Do any of the proposed EVM changes make the data section executable?
4. Do any of the proposed EVM changes create issues with the account proxies?
5. Gas optimizations.
*Disclaimer*: This security review does not guarantee against a hack. It is a snapshot in time of brink according to the specific commit by a three person team. Any modifications to the code will require a new security review.
# Findings
## Low Severity
### Inline assembly leaves dirty higher order bits for `_proxyOwner` variable
**Severity**: Low, Gas optimization
Context: [`Account.sol#L160-L165`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/Account.sol#L160-L165)
```solidity
function proxyOwner() internal view returns (address _proxyOwner) {
assembly {
extcodecopy(address(), mload(0x40), 0x2d, 0x14)
_proxyOwner := mload(sub(mload(0x40), 0x0c))
}
}
```
The expression `mload(sub(mload(0x40), 0x0c))` reads from memory location that was not directly used in the context of `proxyOwner`; more specifically, the memory location, starting from `mload(0x40) - 0x0c` until `mload(0x40)`. Since the contents of this location cannot be predicted (Solidity does not clean up memory after use), the `proxyOwner` variable will have dirty higher order bits, i.e., the most significant 12 bytes (32 - 20) need not be zero.
However, the compiler would clean up this value towards the end of the function, by doing `_proxyOwner := and(2**160 - 1, _proxyOwner)`.
**Recommendation**:
Internally, the Solidity compiler tries to be careful about not leaving dirty higher order bits. Many critical compiler bugs are often the result of the compiler missing such cleanups. We recommend using right shift (`shr`) to properly clean the value read from memory.
```solidity
extcodecopy(address(), mload(0x40), 0x2d, 0x14)
_proxyOwner := shr(0x60, mload(mload(0x40)))
```
This also saves some gas.
Note: The `SHR` (EIP-145) instruction was introduced the same time as `CREATE2`, and since the project relies on `CREATE2` (EIP-1014), this change should not cause any issues, while deploying on other EVM compatible chains. These changes were introduced in the [Petersburg](https://eips.ethereum.org/EIPS/eip-1716) hardfork. For deploying on EVM-compatible chains, we recommend documenting this requirement.
A proof of concept is provided in the [appendix](#proof-of-concept-for-dirty-higher-order-bits).
**Brink**: Fixed in [PR #43](Https://github.com/brinktrade/brink-core/pull/43).
**Spearbit**: Resolved.
### The function `deployAndCall` may silently fail during account creation
**Severity:** Low
Context:
1. [`AccountFactory.sol#L23`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/AccountFactory.sol#L23).
2. [`DeployAndCall.sol#L17`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Batched/DeployAndCall.sol#L17)
The function `deployAndCall` relies on `AccountFactory.deployAccount` to create a new account and to return its address. This function currently just passes through the return value of the underlying `CREATE2` instruction. This instruction will return the value `0` in certain failure cases.
The function `deployAndCall` will then call this newly created account if `callData.length > 0`. In case of a `CREATE2` failure this will result in calling `address(0)`, successfully.
One quirky failure condition of `CREATE2` resulting in `0` is when it runs out of call depth, i.e. it is the 1024th call in the transaction frame. This is fairly easy to accumplish by a malicious actor. In this case `deployAndCall` will silently fail.
**Recommendation:**
A suggested remedy is to have a `require(account != 0);` statement in `AccountFactory.deployAccount`.
Reference: [yellowpaper](https://ethereum.github.io/yellowpaper/paper.pdf#create2).
**Brink**: Fixed in [PR #47](https://github.com/brinktrade/brink-core/pull/47).
**Spearbit**: Resolved.
## Gas Optimizations and Informational
### Hardcode `mload(initCode)` to save 3 gas
**Severity**: Gas Optimization
Context: [`AccountFactory.sol#L23`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/AccountFactory.sol#L23).
```diff
@@ -20,7 +20,7 @@ contract AccountFactory {
owner
);
assembly {
- account := create2(0, add(initCode, 0x20), mload(initCode), SALT)
+ account := create2(0, add(initCode, 0x20), 0x4B, SALT)
}
}
}
```
### Use scratch space in `proxyOwner` to save gas
**Severity**: Gas Optimization
Context: [`Account.sol#L163`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/Account.sol#L163)
Recap the suggested code from the first issue above:
```solidity
extcodecopy(address(), mload(0x40), 0x2d, 0x14)
_proxyOwner := shr(0x60, mload(mload(0x40)))
```
This currently relies on the free memory pointer, which is the adviseable way to use memory. However, for short memory requirements, it is possible to use the so called *scratch space*. From the [`Layout in Memory`](https://docs.soliditylang.org/en/v0.8.10/internals/layout_in_memory.html?#layout-in-memory) section of the Solidity documentation:
> Scratch space can be used between statements (i.e. within inline assembly).
A possible code making use of this is the following:
```solidity
extcodecopy(address(), 0, 0x2d, 0x14)
_proxyOwner := shr(0x60, mload(0))
```
Note that this saves two `MLOAD`s.
Note: While Solidity has not changed the memory layout and these reserved slots for a very long time, it cannot be guaranteed that this will be the case in the future. For this reason we also recommend to leave a comment in the code should this change be enacted.
**Brink**: Fixed in [PR #47](https://github.com/brinktrade/brink-core/pull/47).
**Spearbit**: Resolved.
### Saving 1 byte off the constructor code
**Severity**: Informational
Context: [`AccountFactory.sol#L19`](https://github.com/brinktrade/brink-core/blob/5e7e0d729bb45bbe9bb94f652306a6f24e44e966/contracts/Account/AccountFactory.sol#L19)
The following is the current constructor for the account:
| **PC** | **Opcode** | **Stack** |
|--------|----------------|--------------------------|
| 00000 | RETURNDATASIZE | [0] |
| 00001 | PUSH1 0x41 | [0x41, 0] |
| 00003 | DUP1 | [0x41, 0x41, 0] |
| 00004 | PUSH1 0x0a | [0x0a, 0x41, 0x41, 0] |
| 00006 | RETURNDATASIZE | [0, 0x0a, 0x41, 0x41, 0] |
| 00007 | CODECOPY | [0x41, 0] |
| 00008 | DUP2 | [0, 0x41, 0] |
| 00009 | RETURN | [0] |
However, the `dup2` before the `return` indicates a possible optimization by rearranging the stack. Here, the number `0x0a` denotes the offset of the runtime code. Let's denote this by `offset`, then the following would be a more optimal constructor code:
| **PC** | **Opcode** | **Stack** |
|--------|----------------|----------------------------|
| 00000 | PUSH1 0x41 | [0x41] |
| 00002 | RETURNDATASIZE | [0, 0x41] |
| 00003 | DUP2 | [0x41, 0, 0x41] |
| 00004 | PUSH1 offset | [offset, 0x41, 0, 0x41] |
| 00006 | RETURNDATASIZE | [0, offset, 0x41, 0, 0x41] |
| 00007 | CODECOPY | [0, 0x41] |
| 00008 | RETURN | [] |
**Brink**: Fixed in [PR #47](https://github.com/brinktrade/brink-core/pull/47).
**Spearbit**: Resolved.
### Vanity address optimization
**Severity**: Gas optimization
By finding the appropriate salt for the implementation contract, to make the deployment address have as many zeros as possible, it is possible to save gas for the account factory deployment. This is because one can replace `push20 20-byte-constant` to say, `push16 16-byte-constant`. The latter is 4 bytes shorter than the former, and therefore decreases gas cost for deployment.
The following tool can be used to search for `create2` vanity addresses: [ERADICATE2](https://github.com/johguse/ERADICATE2)
Generally the more time is available for the search, the probability of finding increasing number of leading zeroes goes up. Attaining 2 leading zeroes should be a matter of seconds.
Note: the code of the minimal proxy as well as the code in `proxyOwner()` needs to be updated to support a short address.
Note: a vanity address is most relevant for the `Address.sol`. It might also have a slight advantage for the verifiers. For the minimal proxy, which is deployed per user, it is not important.
**Brink**: Fixed in [PR #47](https://github.com/brinktrade/brink-core/pull/47).
**Spearbit**: Resolved.
### Use `bytes.concat` instead of `abi.encodePacked`
**Severity:** Informational
Context: [`AccountFactory.sol#L16-L21`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/AccountFactory.sol#L16-L21)
Since 0.8.4 it is possible to use `bytes.concat`, which expects literals, `bytes`, and `bytesNN` inputs, and is aimed to replace most use cases of `abi.encodePacked`. It is more expressive, avoids the complex rules of `abi.encodePacked`, and the latter is expected to be phased out in the future.
This suggestion applies throughout the code, but especially in `AccountFactory.deployAccount`, where this would improve readability for showing the layout clearly:
```diff
- bytes memory initCode = abi.encodePacked(
- ....
- owner
- );
+ bytes memory initCode = bytes.concat(
+ ....
+ bytes20(owner)
+ );
```
### Use `<address>.code.length` instead of `extcodesize` in inline assembly
**Severity**: Informational
Context: [`SaltedDeployer.sol#L48-L58`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Deployers/SaltedDeployer.sol#L48-L58)
```diff
function _isContract(address account) internal view returns (bool) {
// This method relies on extcodesize, which returns 0 for contracts in construction, since the code is only stored
// at the end of the constructor execution.
-
- uint256 size;
- assembly {
- size := extcodesize(account)
- }
- return size > 0;
+ return account.code.length > 0;
}
}
```
*Note*: In the past (before 0.8.1), this was inefficient (Solidity used to do an `extcodecopy` to copy the entire code to memory and then calculate the size of this byte array in memory instead of directly using `extcodesize`). But since 0.8.1, Solidity would avoid the memory copy and only use `extcodesize`.
**Brink**: Fixed in [PR #47](https://github.com/brinktrade/brink-core/pull/47).
**Spearbit**: Resolved.
### Use file-level constant for `SALT`
**Severity:** Informational
Context:
1. [`AccountFactory.sol#L9`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/AccountFactory.sol#L9).
2. [`SaltedDeployer.sol#L20`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Deployers/SaltedDeployer.sol#L20).
```solidity
/// @dev Salt used for salted deployments
bytes32 constant SALT = 0x841eb53dae7d7c32f92a7e2a07956fb3b9b1532166bc47aa8f091f49bcaa9ff5;
```
This salt is duplicated in both the contracts `Account/AccountFactory.sol` and `Deployers/SaltedDeployer.sol`.
It may make sense placing the `SALT` as a file-level constant in `AccountFactory` and using that in `SaltedDeployer`. This would reduce the risk of mismatched salt during future changes.
**Brink**: No longer relevant after the salt was set to `0` in [AccountFactory](https://github.com/brinktrade/brink-core/blob/e9ea34edab4681f0d1157eb589f9c613d78da814/contracts/Account/AccountFactory.sol#L24).
**Spearbit**: Resolved.
### Use constants for offsets in `proxyOwner`
**Severity:** Informational
Context: [`Account.sol#L162`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/Account.sol#L162)
```solidity
extcodecopy(address(), mload(0x40), 0x2d, 0x14)
```
The offset `0x2d` is hardcoded in `Account`, but it relies on the layout provided by `AccountFactory`. It may make sense provide a file-level constant in `AccountFactory.sol` and use that:
```solidity
uint256 constant PROXY_OWNER_OFFSET = 0x2d;
```
This would reduce the risk of mismatched offsets during future changes.
### Document that the variable `callData` must have location `memory` in the function `deployAndCall`
**Severity:** Informational
Context: [`DeployAndCall.sol#L16`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Batched/DeployAndCall.sol#L16)
In `Batched/DeployAndCall.sol` the function
```solidity
function deployAndCall(address owner, bytes memory callData) external payable;
```
has the variable `callData` marked as `memory`. By purely looking at the function signature, one would suggest to use the `calldata` location specifier here. This would be incorrect, because the function body uses assembly code relying on the memory layout caused by the `memory` specifier.
It is suggested to include a comment in the code to ensure the location remains unchanged.
### Document that `deployAndCall` may not call the created account
**Severity:** Informational
Context: [`DeployAndCall.sol#L15`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Batched/DeployAndCall.sol#L15)
In `Batched/DeployAndCall.sol` the function `deployAndCall(address owner, bytes memory callData)` deploys a new account and calls into it. While it always deploys a new account, it only calls into it if the `callData` is non-empty.
It is adviseable to document this feature in the NatSpec description.
### Using underscores to improve readability of hex value
**Severity**: Informational
Context: [`AccountFactory.sol#L19`](https://github.com/brinktrade/brink-core/blob/db0027533b228a6994acdbcb06713b5a3a3ecb38/contracts/Account/AccountFactory.sol#L19)
Adding underscore as delimiters improves the readability.
```diff
@@ -15,8 +15,8 @@
contract AccountFactory {
/// address added to the deployed bytecode. The owner address can be read within a delegatecall by using `extcodecopy`
function deployAccount(address owner) external returns (address account) {
bytes memory initCode = abi.encodePacked(
- // [*** constructor **][**** eip-1167 ****]...
- hex'3d604180600a3d3981f3363d3d373d3d3d363d73...
+ // [*** constructor **]_[**** eip-1167 ****]_...
+ hex'3d604180600a3d3981f3_363d3d373d3d3d363d73_...
owner
);
assembly {
```
**Brink**: Fixed in [PR #47](https://github.com/brinktrade/brink-core/pull/47).
**Spearbit**: Resolved.
# Custom proxy code
The contract implements a slightly customized version of the [EIP-1167](https://eips.ethereum.org/EIPS/eip-1167) proxy contract.
## Difference to EIP-1167
The main change is to include an owner address to be used for `NotOwner` checks. This is accomplished with concatenating the address owner to the end of the deployed code. It is done without padding.
Two main concerns arise here:
1. Is it possible for execution to flow into data (the owner address)?
2. Is the address correctly and efficiently read in the `NotOwner` check?
The second question has been addressed in the section ["use scratch space"](#use-scratch-space-in-proxyowner-to-save-gas).
Regarding the first question we need to note that the EVM has no native support for code/data separation, but several proposals are aimed at providing it (e.g. [EIP-2327](https://eips.ethereum.org/EIPS/eip-2327) and [EIP-3540](https://eips.ethereum.org/EIPS/eip-3540)). Save this, we can analyze the control flow. The only control flow instruction is `JUMPI`, which is immediately preceded with a `PUSH1` instruction. We can call this a *static jump*, and conclude that both the destination (the jump) and falling through end up at `RETURN` or `REVERT`, respectively. Also note that several other preceding instructions could abort via various reasons.
One best practice the Solidity compiler does is the insertion of a special marker, the `INVALID` (`0xfe`) instruction, between code and data. This could be done here too, with little benefit.
## Deploy-time
The deploy time code is similar to one in an earlier version of EIP-1167. We have suggested a gas optimisation in the section ["saving 1 byte off the constructor code"](#saving-1-byte-off-the-constructor-code).
See also comments in [ethereum-magicians](https://ethereum-magicians.org/t/discussion-optimized-setup-code/6425).
## Runtime
The runtime code prior to the audit is identical to the one suggested in EIP-1167. We suggest to consider vanity addresses in the section ["vanity address optimization"](#vanity-address-optimization). This suggestion is also mentioned in the EIP.
Additionally one could consider a further optimisation of reordering the stack layout to save on `SWAP`/`DUP` instructions. A method has been described in [this coinmonks article](https://medium.com/coinmonks/the-more-minimal-proxy-5756ae08ee48).
## Remarks
The EIP-1167 proxy code is not easily readable due to optimisations. The varying costs of instructions motivates unconventional code, e.g. `DUPn` and `SWAPn` costs 3 gas, while `RETURNDATASIZE` only costs 2 and is initially set to 0, but can turn to non-zero after certain instructions.
Using `RETURNDATASIZE` is a common practice, but it doesn't come without risks. Proposals could change the semantics of this instruction in certain cases. While this is unlikely to happen, proposals like [EIP-2733](https://eips.ethereum.org/EIPS/eip-2733) do have a slight chance as they do not break existing contract executions, only if they are used in a certain way.
While it is likely a futile attempt to be entirely future proof, one could consider other instructions, such as `MSIZE` (before memory expansion this returns 0), `PC` (is 0 as the first instruction), and using `DUPn` more (which comes at a slight gas increase).
<!-- A template hack -->
\clearpage
# Appendix
## Proof of concept for dirty higher order bits
```solidity
pragma abicoder v1;
contract Test {
bytes32 constant SALT = 0x841eb53dae7d7c32f92a7e2a07956fb3b9b1532166bc47aa8f091f49bcaa9ff5;
address constant random_address = 0x94324fcF2cC42F702F7dCBEe5e61E947DC9e2D91;
address immutable proxy = deployAccount(random_address);
uint256 constant junk = type(uint256).max;
/// deployAccount from AccountFactory.
function deployAccount(address owner) internal returns (address account) {
...
}
/// Note: returns bytes32 instead of address;
/// so that the compiler does not perform cleanup.
function proxyOwner(address _proxy) internal view returns (bytes32 _proxyOwner) {
assembly {
extcodecopy(_proxy, mload(0x40), 0x2d, 0x14)
_proxyOwner := mload(sub(mload(0x40), 0x0c))
}
}
/// returns
/// 0xffffffffffffffffffffffff94324fcf2cc42f702f7dcbee5e61e947dc9e2d91
/// instead of
/// 0x94324fcf2cc42f702f7dcbee5e61e947dc9e2d91
function test() external returns (bytes32) {
assembly {
// Store junk at the current free memory
mstore(mload(0x40), junk)
// Increment the free memory pointer
mstore(0x40, add(mload(0x40), 0x20))
}
return proxyOwner(proxy);
}
}
```
