MongoEngine Inside

the Detail of MongoDB & MongoEngine

郭學聰 Hsueh-Tsung KuoSat, 02 Jun 2018

who am I?

fieliapm

programmer from Rayark, a game company in Taiwan
backend engineer, focus on common service
usually develop something related to my work in Python, Ruby, Golang, C#
built almost entire VOEZ game server by myself only
supported Sdorica backend development

outline

when MongoEngine
1. PyMongo vs MongoEngine
from ORM to BSON
1. deserialize & ~~serialize~~ set
2. dereferencing
3. pass needed fields "ONLY" (twice meaning)
race condition
1. commands for updating data atomically
2. ORM design & atomic
  1. denormalization
  2. referencing

index
1. index detail
  1. sortable or hash (non sortable)
  2. unique index
  3. array field & index
  4. others
2. compound index
  1. efficient query casestudy
  2. how to assign efficient compound index
migration
1. slow python meets time limited huge data migration

conclusion
commercial
Q&A

when MongoEngine

PyMongo vs MongoEngine

PyMongo
- dict everywhere
- query filter
MongoEngine
- Object Relational Mapping
- Django query syntax




# PyMongo
mongoClient['db']['collection'].insert({'first': {'second': {'third': 5}}})

mongoClient['db']['collection'].find({'first.second.third': {'$gte': 4}})






# MongoEngine
doc = Doc()
doc.first.second.third = 5
doc.save()

Doc.objects(first__second__third__gte=4)

from ORM to BSON

ORM usage

















class HighScore(mongoengine.document.Document):
    stage = mongoengine.fields.StringField(required=True)
    mode = mongoengine.fields.StringField(required=True)
    username = mongoengine.fields.StringField(required=True)
    score = mongoengine.fields.FloatField(required=True)
    timestamp = mongoengine.fields.DateTimeField(required=True)
    meta = {
        'indexes': [
            {
                'fields': ['stage', 'mode', '-score', '-timestamp', 'username'],
            },
            {
                'fields': ['stage', 'mode', 'username'],
                'unique': True,
            },
        ],
    }

Python descriptors



field.__get__(self, doc, type=None) --> value
field.__set__(self, doc, value) --> None
field.__delete__(self, doc) --> None

deserialize & serialize set

deserialize object from BSON

mongoengine/queryset/base.py




















class BaseQuerySet(object):
......
    def next(self):
......
        if self._limit == 0 or self._none:
            raise StopIteration

        raw_doc = self._cursor.next()

        if self._as_pymongo:
            return self._get_as_pymongo(raw_doc)

        doc = self._document._from_son(
            raw_doc, _auto_dereference=self._auto_dereference,
            only_fields=self.only_fields)

        if self._scalar:
            return self._get_scalar(doc)

        return doc

change field value

mongoengine/base/fields.py













class BaseField(object):
......
    def __set__(self, instance, value):
......
        if instance._initialised:
            try:
                if (self.name not in instance._data or
                        instance._data[self.name] != value):
                    instance._mark_as_changed(self.name)
            except Exception:
                # Values cant be compared eg: naive and tz datetimes
                # So mark it as changed
                instance._mark_as_changed(self.name)

save document after changing field value

mongoengine/document.py













class Document(BaseDocument):
......
    def save(self, force_insert=False, validate=True, clean=True,
             write_concern=None, cascade=None, cascade_kwargs=None,
             _refs=None, save_condition=None, signal_kwargs=None, **kwargs):
......
        try:
            # Save a new document or update an existing one
            if created:
                object_id = self._save_create(doc, force_insert, write_concern)
            else:
                object_id, created = self._save_update(doc, save_condition,
                                                       write_concern)







    def _save_update(self, doc, save_condition, write_concern):
......
        update_doc = self._get_update_doc()
        if update_doc:
            upsert = save_condition is None
            last_error = collection.update(select_dict, update_doc,
                                           upsert=upsert, **write_concern)











    def _get_update_doc(self):
......
        updates, removals = self._delta()

        update_doc = {}
        if updates:
            update_doc['$set'] = updates
        if removals:
            update_doc['$unset'] = removals

        return update_doc

dereferencing

mongoengine/fields.py









class ReferenceField(BaseField):
......
    def __get__(self, instance, owner):
......
            dereferenced = cls._get_db().dereference(value)
            if dereferenced is None:
                raise DoesNotExist('Trying to dereference unknown document %s' % value)
            else:
                instance._data[self.name] = cls._from_son(dereferenced)

disadvantage & workaround

read all referenced document just for one field
LazyReferenceField
- get
- set
- delete

pass needed fields "ONLY" (twice meaning)

query speed
- part of document > whole document
transfer size
- part of document < whole document


high_scores_1 = HighScore.objects(...).only('username')
high_scores_2 = HighScore.objects(...).exclude('timestamp')


high_score_1.save()

mongoengine.errors.ValidationError:
ValidationError (HighScore:0123456789abcdef01234567)
(Field is required: ['mode', 'song', 'score', 'timestamp'])

full control PyMongo

race condition

commands for updating data atomically






# findAndModify(), single
old_high_score = HighScore.objects(stage='stage1', mode='hard', username='woshige')
        .modify(set__score=0.0)
# update(), single or multiple
HighScore.objects(stage='stage1', mode='hard')
        .update(multi=True, inc__score=100000.0)

ORM design & atomic

buddha_database

denormalization

one operation to one document at same time
large BSON -> docment size limit
example
- player data update

service->database: update()
service->database: Doc.objects(doc='doc2').modify()
note right of database: collide at document2 ?
database-->service: old document2
database-->service: update() status

gantt
    title one operation to one document at same time
    section update()
    update document1 :done,u1,2018-06-02,1s
    update document2 :active,u2,after u1,1s
    update document3 :u3,after m1,1s
    section modify()
    modify document2 :crit,active,m1,after u2,1s

referencing

DIY lock or state
small BSON
example
- player coin -> guild coin

note right of service: unique index ['player', 'guild']
service->database: Transaction(player='1', guild='a', coin=100).save()
note right of database: session start
service->database: Player.objects(player="1").update(inc__coin=-100)
service->database: Transaction(player='1', guild='a', coin=200).save()
note right of database: fail!
service->database: Guild.objects(guild="a").update(inc__coin=100)
service->database: Transaction.objects(player='1', guild='a').delete()
note right of database: session end

gantt
    title modify two documents
    section transaction1
    start transaction :done,t1s,2018-06-02,1s
    player coin -100  :active,p1,after t1s,1s
    guild coin +100   :active,g1,after p1,1s
    end transaction   :t1e,after g1,1s
    section transaction2
    start transaction fail :crit,done,t2s,2018-06-02T00:00:01.5,1s

Perform Two Phase Commits

https://docs.mongodb.com/manual/tutorial/perform-two-phase-commits/

index

index detail

sortable or hash (non sortable)

sortable
- equal, range, sort query
- multikey
- range sharding
hash
- equal query only
- no multikey
- hash sharding
  - randomize

unique index

ensures that the indexed fields do not store duplicate values

















class HighScore(mongoengine.document.Document):
    stage = mongoengine.fields.StringField(required=True)
    mode = mongoengine.fields.StringField(required=True)
    username = mongoengine.fields.StringField(required=True)
    score = mongoengine.fields.FloatField(required=True)
    timestamp = mongoengine.fields.DateTimeField(required=True)
    meta = {
        'indexes': [
            {
                'fields': ['stage', 'mode', '-score', '-timestamp', 'username'],
            },
            {
                'fields': ['stage', 'mode', 'username'],
                'unique': True,
            },
        ],
    }

array field & index

multikey index
- index key for each element in array

multikey index

digraph {
    nodesep=0.5
    node[color="magenta",fontname="Courier",shape="box"]
    edge[color="orange",style="dashed"]
    "addr.zip"->{"\"10036\"" "\"94301\""}
    "\"10036\""->"{\l     userid: \"xyz\",\l     addr: [\l         {zip: \"10036\", ...},\l         {zip: \"94301\", ...}\l     ],\l     ...\l}\l"
    "\"94301\""->"{\l     userid: \"xyz\",\l     addr: [\l         {zip: \"10036\", ...},\l         {zip: \"94301\", ...}\l     ],\l     ...\l}\l"
    {rank=same;"\"10036\"" "\"94301\""}
}

others

string search
- text
geospatial
- 2d
- 2dsphere
- geoHaystack

compound index

single index structure holds references to multiple fields

















class HighScore(mongoengine.document.Document):
    stage = mongoengine.fields.StringField(required=True)
    mode = mongoengine.fields.StringField(required=True)
    username = mongoengine.fields.StringField(required=True)
    score = mongoengine.fields.FloatField(required=True)
    timestamp = mongoengine.fields.DateTimeField(required=True)
    meta = {
        'indexes': [
            {
                'fields': ['stage', 'mode', '-score', '-timestamp', 'username'],
            },
            {
                'fields': ['stage', 'mode', 'username'],
                'unique': True,
            },
        ],
    }

digraph {
    nodesep=0.1
    node[color="magenta",fontname="Courier",shape="box"]
    edge[color="orange",style="dashed"]
    "['stage', 'mode', 'username']"->{"stage1" "stage2" "stage3"}
    "stage1"->{"easy" "normal" "hard"}
    "stage2"->{"easy " "normal " "hard "}
    "stage3"->{" easy " " normal " " hard "}
    "easy"->{"#" "q"}
    "normal"->"w"
    "hard"->"e"
    "easy "->"r"
    "normal "->"t"
    "hard "->"y"
    " easy "->"u"
    " normal "->"i"
    " hard "->{"o" "p"}
}

index can help query







HighScore.objects(stage='stage1', mode='hard', username='woshige')
HighScore.objects(stage='stage1', mode='hard')
HighScore.objects(stage='stage1')

HighScore.objects(stage='stage1', mode='hard', score__gte=1000000.0)
HighScore.objects(stage='stage1', mode='hard').order_by('-score', '-timestamp')
HighScore.objects(stage='stage1', mode='hard').order_by('-score')

index cannot help query






HighScore.objects(stage='stage1', username='woshige')
HighScore.objects(mode='hard', username='woshige')
HighScore.objects(mode='hard')
HighScore.objects(username='woshige')

HighScore.objects(stage='stage1', mode='hard').order_by('-timestamp')

efficient query casestudy


query_plan = HighScore.objects(...).explain()






















# MongoDB 3.x
{
    ......
    'executionStages': {
        'stage': 'SORT', # sort with CPU & RAM (true) or walk through sortable index (false)
    },
    ......
    'nReturned': 1, # number of documents that match the query condition
    'totalDocsExamined': 3, # number of documents scanned
    'totalKeysExamined': 5, # number of index entries scanned
    ......
}

# MongoDB 2.x
{
    ......
    'n' : 1, # number of documents that match the query condition
    'nscannedObjects': 3, # number of documents scanned
    'nscanned': 5, # number of index entries scanned
    'scanAndOrder': false # sort with CPU & RAM (true) or walk through sortable index (false)
    ......
}

stage = 10
mode = 3
user = 100
high score document count = 3000

equal + range















HighScore.objects(stage='stage1', mode='hard', username__gte='w').explain()

# ['username', 'stage', 'mode']
{
    'nReturned': 12,
    'totalDocsExamined': 12,
    'totalKeysExamined': 47,
}

# ['stage', 'mode', 'username']
{
    'nReturned': 12,
    'totalDocsExamined': 12,
    'totalKeysExamined': 12,
}

equal + sort
















HighScore.objects(stage='stage1', mode='hard')
    .order_by('-score', '-timestamp').explain()

# ['-score', '-timestamp', 'stage', 'mode']
{
    'nReturned': 100,
    'totalDocsExamined': 3000,
    'totalKeysExamined': 3000,
}

# ['stage', 'mode', '-score', '-timestamp']
{
    'nReturned': 100,
    'totalDocsExamined': 100,
    'totalKeysExamined': 100,
}

equal + sort + range






































HighScore.objects(stage='stage1', mode='hard', username__gte='w')
    .order_by('-score', '-timestamp').explain()

# ['-score', '-timestamp', 'stage', 'mode', 'username']
{
    'nReturned': 12,
    'totalDocsExamined': 3000,
    'totalKeysExamined': 3000,
}

# ['username', '-score', '-timestamp', 'stage', 'mode']
{
    'executionStages': {
        'stage': 'SORT',
    },
    .....
    'nReturned': 12,
    'totalDocsExamined': 12,
    'totalKeysExamined': 48,
}

# ['username', 'stage', 'mode', '-score', '-timestamp']
{
    'executionStages': {
        'stage': 'SORT',
    },
    .....
    'nReturned': 12,
    'totalDocsExamined': 12,
    'totalKeysExamined': 47,
}

# ['stage', 'mode', '-score', '-timestamp', 'username']
{
    'nReturned': 12,
    'totalDocsExamined': 12,
    'totalKeysExamined': 101,
}

"do not sort through database!!!"
Hsueh-Tsung KuoSat, 02 Jun 2018

how to assign efficient compound index

the gold indexing slogan
- equal
- sort
- range

reference:
- https://emptysqua.re/blog/optimizing-mongodb-compound-indexes/
- http://developers-club.com/posts/147053/

migration

slow python meets time limited huge data migration



# update(), single or multiple
HighScore.objects(stage='stage1', mode='hard')
        .update(multi=True, inc__score=100000.0)

conclusion

buddha_database

"equal, sort, range"
Hsueh-Tsung KuoSat, 02 Jun 2018

special thanks

Rayark Inc.
- CTO & CIO
- Sdorica team
- backend team
- QA team
- customer service team
- IT team
- other teams
iKala Interactive Media Inc.

commercial

Sdorica -sunset-

OP Animation https://youtu.be/ktGRO8tCBqs
Global Launch Trailer https://youtu.be/2aY7il7zuNk
Background Story https://youtu.be/9tOmgueeY7I

Rayark Wants You !

Rayark Careers | Make A Difference

Syntax	Example	Reference
# Header	Header	基本排版
- Unordered List	Unordered List
1. Ordered List	Ordered List
- [ ] Todo List	Todo List
> Blockquote	Blockquote
Bold font	Bold font
Italics font	Italics font
~~Strikethrough~~	~~Strikethrough~~
19^th^	19^th
H~2~O	H₂O
++Inserted text++	Inserted text
==Marked text==	Marked text
[link text](https:// "title")	Link
![image alt](https:// "title")	Image
`Code`	`Code`	在筆記中貼入程式碼
```javascript var i = 0; ```	`var i = 0;`	在筆記中貼入程式碼
:smile:		Emoji list
{%youtube youtube_id %}	Externals
$L^aT_eX$	L^aT_eX
:::info This is a alert area. :::	This is a alert area.

MongoEngine Inside

who am I?

outline

when MongoEngine

PyMongo vs MongoEngine

from ORM to BSON

deserialize & serialize set

deserialize object from BSON

change field value

save document after changing field value

dereferencing

disadvantage & workaround

pass needed fields "ONLY" (twice meaning)

race condition

commands for updating data atomically

ORM design & atomic

denormalization

referencing

index

index detail

sortable or hash (non sortable)

unique index

array field & index

others

compound index

efficient query casestudy

how to assign efficient compound index

migration

slow python meets time limited huge data migration

conclusion

special thanks

commercial

Rayark Wants You !

Q&A
