# LAN PROJECT Part 1: DNS, DHCP and FTP Servers on Ubuntu 22.04 LTS
[TOC]

## VM Structures
We're using VMware Workstation 16.2.x with the following machines:

#### Running on Ubuntu 22.04 LTS server
Download:
https://releases.ubuntu.com/jammy/ubuntu-22.04.2-live-server-amd64.iso

#### Netplan configuration for ns1 and ftp

# This is the network config written by 'subiquity'
network:
  ethernets:
    ens32:    ~#Internal Network
      dhcp4: true
    ens34:     #WAN Network
      dhcp4: true
  version: 2

#### Netplan configuration for dhcp1

# This is the network config written by 'subiquity'
network:
  ethernets:
    ens32:
      dhcp4: false
      addresses:
         - 192.168.174.10/24
      nameservers:
        addresses: [192.168.174.20]
        search: [ data.eibanez.cf ]
    ens34:
      dhcp4: true
  version: 2

#### Netplan configuration for hosts

# This is the network config written by 'subiquity'
network:
  ethernets:
    ens32:    ~#Internal Network
      dhcp4: true
  version: 2

#### MAC Address
You can check your MAC Address from the machine's Network Adapter -> Advanced Configuration

Alternatively log in into your machine and run the following command

ip a


#### Network planification
dhcp1 ens32: 192.168.174.10 - 00:0C:29:57:59:10
ns1 ens32: 192.168.174.20 - 00:50:56:3C:2F:B8
ftp1 ens32: 192.168.174.30 - 00:0c:29:fb:8e:67
host1 ens32: 192.168.174.10 - 00:50:56:39:A8:2D
host2 ens32: 192.168.174.10 - 00:50:56:3A:C0:CF

## DHCP Server
First let's change our hostname

sudo hostnamectl set-hostname dhcp1

Then we'll update our repositories

sudo apt update

We install the isc-dhcp-server

sudo apt install isc-dhcp-server

Now we can change the configuration file

sudo nano /etc/dhcp/dhcpd.conf

This is what our dhcpd.conf file would look like

# dhcpd.conf
#
# Sample configuration file for ISC dhcpd
#
# Attention: If /etc/ltsp/dhcpd.conf exists, that will be used as
# configuration file instead of this file.
#

# option definitions common to all supported networks...
# option domain-name "eibanez.cf";
# option domain-name-servers ns1.data.eibanez.cf;

default-lease-time 600;
max-lease-time 7200;

# The ddns-updates-style parameter controls whether or not the server will
# attempt to do a DNS update when a lease is confirmed. We default to the
# behavior of the version 2 packages ('none', since DHCP v2 didn't
# have support for DDNS.)
ddns-update-style none;

# If this DHCP server is the official DHCP server for the local
# network, the authoritative directive should be uncommented.
authoritative;

# A slightly different configuration for an internal subnet.

subnet 192.168.174.0 netmask 255.255.255.0 {
  range 192.168.174.100 192.168.174.199;
  option domain-name-servers ns1.data.eibanez.cf;
  option domain-name "data.eibanez.cf";
  option subnet-mask 255.255.255.0;
  option routers 192.168.174.2;
  option broadcast-address 192.168.174.255;
  default-lease-time 600;
  max-lease-time 7200;
}

# Reserving addresses through the MAC address for our machines
host ns1 {
  hardware ethernet 00:50:56:3C:2F:B8;
  fixed-address 192.168.174.20;
}

host dhcp1 {
  hardware ethernet 00:0C:29:57:59:10;
  fixed-address 192.168.174.10;
}

host ftp1 {
  hardware ethernet 00:0c:29:fb:8e:67;
  fixed-address 192.168.174.30;
}

host host1 {
  hardware ethernet 00:50:56:39:A8:2D;
  fixed-address 192.168.174.100;
}

host host2 {
  hardware ethernet 00:50:56:3A:C0:CF;
  fixed-address 192.168.174.101;
}

We can check our configuration file using this command

dhcpd -t -cf /etc/dhcp/dhcpd.conf


Now we can restart the service and check if it's working

sudo systemctl enable isc-dhcp-server
sudo systemctl restart isc-dhcp-server.service
sudo systemctl status isc-dhcp-server


We can also check our logs using journalctl

journalctl -u isc-dhcp-server

## DNS Server
### Setup of Bind9
First let's change our hostname

sudo hostnamectl set-hostname ns1

Then we'll update our repositories

sudo apt update

To begin the installation process, open the terminal and execute the following command:

sudo apt install bind9 bind9utils bind9-doc

### Configuration files
#### named.conf.options
Let's modify our options file

sudo nano /etc/bind/named.conf.options

We'll uncomment and add the following lines

options {
        directory "/var/cache/bind";
        recursion yes;                 # enables recursive queries
        allow-recursion { localnets; };# Allow recursion to local network
        listen-on { 192.168.174.20; }; # ns1 private IP address
        allow-transfer { none; };      # disable zone transfers by default
        forwarders {                   # Cloudflare forwarders
            1.1.1.1;
            1.0.0.1;
        };
        dnssec-validation auto;
        listen-on-v6 { any; };
};


#### named.conf.local
Let's modify our local file

sudo nano /etc/bind/named.conf.local

Let's add our primary and reverse zones

//
// Do any local configuration here
//

// Consider adding the 1918 zones here, if they are not used in your
// organization
//include "/etc/bind/zones.rfc1918";
# Primary Zone
zone "data.eibanez.cf" {
    type primary;
    file "/etc/bind/zones/db.data.eibanez.cf";          # Zone file path
};

zone "174.168.192.in-addr.arpa" {
    type primary;
    file "/etc/bind/zones/db.174.168.192";              # Reverse zone 192.168.174.0/24 subnet
};


### Zone Files
#### /etc/bind/zones Directory
Create the directory:

sudo mkdir /etc/bind/zones

Copy the local file to the zone directory:

sudo cp /etc/bind/db.local /etc/bind/zones/db.data.eibanez.cf

Edit the zone file:

sudo nano /etc/bind/zones/db.data.eibanez.cf

Define the Start of Authority (SOA) using the FQDN of your primary DNS server (ns1). Increment the serial value +1:

;
$TTL    604800
@       IN      SOA     ns1.data.eibanez.cf. root.data.eibanez.cf. (
                              3         ; Serial

We'll delete the last 3 entries as they're the localhost ones.
Specify the NS records that point to your DNS server:

; name servers - NS records
        IN      NS      ns1.data.eibanez.cf.

Add the A records for your DNS server and clients:

; name servers - A records
ns1.data.eibanez.cf.          IN      A       192.168.174.20

; 192.168.174.0/24 - A records
dhcp1.data.eibanez.cf.        IN      A      192.168.174.10
ftp1.data.eibanez.cf.         IN      A      192.168.174.30
host1.data.eibanez.cf.        IN      A      192.168.174.100
host2.data.eibanez.cf.        IN      A      192.168.174.101


#### Reverse Zone File
Copy the example file to create the reverse zone:

sudo cp /etc/bind/db.127 /etc/bind/zones/db.174.168.192

Edit the reverse zone file:

sudo nano /etc/bind/zones/db.174.168.192

Increment the serial value in the SOA record and add FQDN:

@       IN      SOA     ns1.data.eibanez.cf. root.data.eibanez.cf. (
                              2         ; Serial

Add the NS records for your DNS servers:

; name servers - NS records
        IN      NS      ns1.data.eibanez.cf.

Add the PTR records for the IP addresses in your zone (192.168.174.0/24):

; PTR Records
10      IN      PTR     dhcp1.data.eibanez.cf.          ; 192.168.174.10
20      IN      PTR     ns1.data.eibanez.cf.            ; 192.168.174.20
30      IN      PTR     ftp1.data.eibanez.cf.           ; 192.168.174.30
100     IN      PTR     host1.data.eibanez.cf.          ; 192.168.174.100
101     IN      PTR     host2.data.eibanez.cf.          ; 192.168.174.101


### Final Configuration
To ensure the configuration files are correct, run the following commands:

sudo named-checkconf
sudo named-checkzone data.eibanez.cf /etc/bind/zones/db.data.eibanez.cf
sudo named-checkzone 174.168.192.in-addr.arpa /etc/bind/zones/db.174.168.192

Restart the BIND service:

sudo systemctl restart bind9

Allow Bind9 through UFW Firewall:

sudo ufw allow Bind9

And you should be done!

sudo systemctl status bind9


We can always check our logs with Journalctl

journalctl -u named

## FTP Server
### Initial setup of PROFTPD
Setting our hostname

sudo hostnamectl set-hostname ftp1

Updating our repositories

sudo apt update

Now we can begin the installation

sudo apt -y install proftpd

If we want to implement tls/sftp we'll also install the crypto mod

sudo apt -y install proftpd-mod-crypto

Now we can check if the service is running through systemctl

sudo systemctl status proftpd


Logs with journalctl

journalctl -u proftpd

Correct configuration syntax with proftpd -t

proftpd -t

### User management
PROFTPD will use the regular UNIX users as the method of authentication.
We can create a new user with this command:

sudo adduser ftp1


We'll log with the user

su ftp1

Place a few things to play with in it's home directory

You can quit this user's session with the command:

exit


We can also modify their home directory with this command where **/var/www/** is the path to the new home.

sudo usermod -m -d /var/www/ username

### Use of FTP
We can log from our network using the command:

ftp ftp1@192.168.174.30

You'll be prompted for the password

Once inside you can type **help** to get the commands

**dir** or **ls** is used to see what's inside our directory

**delete** erases a file

**cd** to change directories

**put** uploads a file from the host directory

**get** downloads a file

**exit** to leave ftp

### Auto-signed certificates
To enable FTPS and SFTP we need encryption, we can get an auto-signed certificates through one of these commands:
1. Install SSL in case we don't have it

sudo apt-get install openssl -y

2. **Gencert**

sudo proftpd-gencert


or

2. **OpenSSL**

sudo openssl req -x509 -nodes -days 365 -newkey rsa:2048 -keyout /etc/ssl/private/proftpd.key -out /etc/ssl/certs/proftpd.crt

Change the permissions on these files

sudo chmod 0600 /etc/ssl/private/proftpd.key
sudo chmod 0600 /etc/ssl/certs/proftpd.crt

### Configuration files
#### proftpd.conf
This is the general configuration file, we'll modify it using the following command:

sudo nano /etc/proftpd/proftpd.conf

##### Enable TLS
Uncomment this line

Include /etc/proftpd/tls.conf


##### Enable SFTP
Uncomment this to enable SFTP:

Include /etc/proftpd/sftp.conf


##### Anonymous users
We could activate anonymous users uncommenting the following lines:

 <Anonymous ~ftp>
   User ftp
   Group nogroup
   # We want clients to be able to login with "anonymous" as well as "ftp"
   UserAlias anonymous ftp
   # Cosmetic changes, all files belongs to ftp user
   DirFakeUser on ftp
   DirFakeGroup on ftp

   RequireValidShell off

   # Limit the maximum number of anonymous logins
   MaxClients 10

   # We want 'welcome.msg' displayed at login, and '.message' displayed
   # in each newly chdired directory.
#   DisplayLogin welcome.msg
#   DisplayChdir .message
#
#   # Limit WRITE everywhere in the anonymous chroot
#   <Directory *>
#     <Limit WRITE>
#       DenyAll
#     </Limit>
#   </Directory>
#
#   # Uncomment this if you're brave.
#   # <Directory incoming>
#   #   # Umask 022 is a good standard umask to prevent new files and dirs
#   #   # (second parm) from being group and world writable.
#   #   Umask022  022
#   #   <Limit READ WRITE>
#   #     DenyAll
#   #     </Limit>
#   #       <Limit STOR>
#   #         AllowAll
#   #     </Limit>
#   # </Directory>
#
 </Anonymous>

#### sftp.conf
Modify the file

sudo nano /etc/proftpd/sftp.conf

Uncomment these lines

<IfModule mod_sftp.c>
SFTPEngine     on
Port           2222
SFTPLog        /var/log/proftpd/sftp.log
SFTPHostKey /etc/ssh/ssh_host_rsa_key
</IfModule>

#### tls.conf
Modify the file

sudo nano /etc/proftpd/sftp.conf

To get TLS working we have to uncomment these lines

<IfModule mod_tls.c>
TLSEngine                               on
TLSLog                                  /var/log/proftpd/tls.log
TLSProtocol                             SSLv23
TLSRSACertificateFile                   /etc/ssl/certs/proftpd.crt
TLSRSACertificateKeyFile                /etc/ssl/private/proftpd.key
TLSOptions                              AllowClientRenegotiations
TLSRequired                             on
</IfModule>

#### modules.conf
##### TLS Activation
Uncomment these lines

# Install proftpd-mod-crypto to use this module for TLS/SSL support.
LoadModule mod_tls.c
# Even these modules depend on the previous one
LoadModule mod_tls_fscache.c
LoadModule mod_tls_shmcache.c

##### SFTP Activation
Uncomment these lines

# Install proftpd-mod-crypto to use this module for SFTP support.
LoadModule mod_sftp.c
LoadModule mod_sftp_pam.c

### TLS testing
Once the required configuration files of proftpd.conf, tls.conf and modules.conf have been modified we can restart and check our service

sudo systemctl restart proftpd.service
sudo systemctl status proftpd.service


Now since we enabled TLSRequired On we won't be able to connect through normal ftp

We can install ftp-ssl to connect securely

sudo apt install ftp-ssl

Now we can connect using the command ftp-ssl **server name**

ftp-ssl ftp1

We'll be prompted by the user name and password

### SFTP Testing
We'll test our connection with the sftp command:

sftp ftp1@192.168.174.30

We'll accept the key by typing **yes** and enter the password

## Hosts
Since we're in a private network we only have to enable dhcp4 in our netplan

sudo nano /etc/netplan/00-installer-config.yaml

And we set dhcp to **true**

# This is the network config written by 'subiquity'
network:
  ethernets:
    ens32:    ~#Internal Network
      dhcp4: true
  version: 2

Now we can check our connection through this command

ip a


We can confirm that our DNS is working properly through the following commands

resolvectl status


nslookup ftp1


dig dhc1.data.eibanez.cf


host 192.168.174.30
