--- tags: machine-learning --- # Convolutional Neural Network with Numpy (Fast) <div style="text-align: center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/0.png" width="80%"> </div> > In the [previous post](https://hackmd.io/@machine-learning/blog-post-cnnumpy-slow), we have seen a naive implementation of Convolutional Neural network using Numpy. > > Here, we are going to implement a faster CNN using Numpy with the im2col/col2im method. > > To see the full implementation, please refer to my [repository](https://github.com/3outeille/CNNumpy). > > Also, if you want to read some of my blog posts, feel free to check them at my [blog](https://3outeille.github.io/deep-learning/). # I) Forward propagation :::info - The main objective here is to ensure that the reader develops a strong intuition about how im2col/col2im works so that he can write them by himself. - Thus, I decided to be less **rigorous** in my explanation to make things **clearer**. - We will refer to the term "**level**" as a whole horizontal kernel slide from left to right. - We will only discuss **average pooling** layer here (even though same logic can be applied on max pooling). ::: ## 1) Convolutional layer - In the naive implementation, we used a lot of nested "For loops" which makes our code very slow. - An approach could be to trade some memory for more speedup. - Here are the following steps: - **A.** ==Transform our input image into a matrix (im2col).== - **B.** ==Reshape our kernel (flatten).== - **C.** ==Perform matrix multiplication between reshaped input image and kernel.== - We are going to see how it works intuitively and then how to implement it using Numpy. ## ☰ Intuition - As an example, we will perform a convolution between an (1,3,4,4) input image and kernels of shape (2,3,2,2). ### A) <ins>Transform our input image into a matrix (im2col)</ins> - Here is how it works: <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/1.gif"> <figcaption>Figure 1: Input image transformed into matrix</figcaption> </div> <br> - How do we do that in Numpy? An efficient way to do so is by the help of [multi-dimensional arrays indexing](https://docs.scipy.org/doc/numpy/user/basics.indexing.html). For example, python >>> y = np.arange(35).reshape(5,7) >>> y array([[ 0, 1, 2, 3, 4, 5, 6], [ 7, 8, 9, 10, 11, 12, 13], [14, 15, 16, 17, 18, 19, 20], [21, 22, 23, 24, 25, 26, 27], [28, 29, 30, 31, 32, 33, 34]]) >>> y[np.array([0,2,4]), np.array([0,1,2])] array([0, 15, 30]) # 0 = (0,0) / 15 = (2,1) / 30 = (4,2)  - Thus, the idea is to use **the multi-dimensional arrays indexing** property to transform our input image into a matrix. - Indeed, we can notice few things: - **Firstly**, the indices for each input image channel is the same. Thus, we can focus ourselves only on the first channel since the result will be the same for the others. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/2.png" width="90%"> </div> - **Secondly**, we can observe a certain pattern in the indices (<a style="color:red">i</a>, <a style="color:#FF1493">j</a>) when we slide our kernel. <br> - <a style="color:red"><ins>Index i</ins></a>: - At level 1, we have: ![](https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/3.png) - At level 2, we have: ![](https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/4.png) - At level 3, we have: ![](https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/5.png) - <a style="color:red"><ins>Conclusion:</ins></a> - We start with a [0, 0, 1, 1] vector at level 1. - **At each level, we increase the vector by 1.** <br> - <a style="color:#FF1493"><ins>Index j</ins></a>: - At level 1, we have: ![](https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/6.png) - At level 2, we have: ![](https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/7.png) - At level 3, we have: ![](https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/8.png) - <a style="color:#FF1493"><ins>Conclusion:</ins></a> - At the level 1, there is a total of 3 slides. - For slide 1, we have a [0,1,0,1] vector. - For slide 2, we have a [1,2,1,2] vector. - For slide 3, we have a [2,3,2,3] vector. - **We can notice an increase of 1 at each slide.** - **At each level, we keep the same pattern.** --- - Thus, even if it's not rigorous, we can intuitively think of a general formula for an **(n,n) image convolve to $X$ filters of shape (k, k)**. <br> - <a style="color:red"><ins>For index i</ins></a>: <br> - We start with at level 1 with the following vector: $$[\underbrace{0,0,...0}_{k},\underbrace{1,1,...1}_{k},...,\underbrace{k-1,k-1,...,k-1}_{k}]$$ - ==**At each level, we increase this vector by 1**== <br> - <a style="color:#FF1493"><ins>For index j</a></ins>: <br> - At level 1, there is a total of n-k slides. <br> - For slide 1, we have a $[\underbrace{0,1,...,k-1,...,0,1,...,k-1}_{k}]$ vector. - For slide 2, we have a $[\underbrace{1,2,...,k,...,1,2,...,k}_{k}]$ vector. - ... - For slide n-k, we have a $[\underbrace{n-k,n-k+1,...,n-1,...,n-k,n-k+1,...,n-1}_{k}]$ vector. - ==**At each level, we keep the same pattern.**== <br> - The numbers of filters $X$ do not have any effect in this part. We will see that it's quite simple to deal with it during the kernel reshaping step. - If you have $M$ images ($M > 1$), you will have the same matrix but stack horizontally $M$ times. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/9.gif"> </div> ### B) <ins>Reshape our kernel (flatten)</ins> - Here is how it works: <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/10.png" width="80%"> <figcaption>Figure 2: Reshaped version of the 2 kernels</figcaption> </div> <br> - As you can see, each filter is flattened and then stacked together. Thus, for $X$ filter, we will flatten and stack $X$ filters together. ### C) <ins>Matrix multiplication between reshaped input and kernel</ins> - Now, we only need to perform a matrix multiplication. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/11.gif"> <figcaption>Figure 3: Matrix multiplication</figcaption> </div> <br> - At the end, we need to reshape our matrix back to an image. - ==Be aware the np.reshape() method doesn't return the expected result here (elements in wrong order). A little bit of numpy gymnastic solves the problem.== ## ☰ Implementation - The most difficult part of im2col is to **transform our input image into a matrix.** - To do so, we will use np.tile() and np.repeat() methods from Numpy. Here is how they work: python >>> y = np.arange(5) >>> y array([0, 1, 2, 3, 4]) >>> np.tile(y, 2) array([0, 1, 2, 3, 4, 0, 1, 2, 3, 4]) >>> np.repeat(y, 2) array([0, 0, 1, 1, 2, 2, 3, 3, 4, 4])  - Now, let's explain the process visually. :::info **Reminder:** - We want to perform a convolution between an (1,3,4,4) input image kernels of shape (2,3,2,2). ::: - For index i: <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/12-a.png"> </div> <br> <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/12-b.png"> </div> <br> <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/12-c.gif"> </div> <br> - For index j: <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/13-a.png"> </div> <br> <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/13-b.png"> </div> <br> <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/13-c.gif"> </div> <br> - Now, we can transform our input image into a matrix. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/14.gif"> </div> <br> --- Here is the code to implement **im2col**: python= def get_indices(X_shape, HF, WF, stride, pad): """ Returns index matrices in order to transform our input image into a matrix. Parameters: -X_shape: Input image shape. -HF: filter height. -WF: filter width. -stride: stride value. -pad: padding value. Returns: -i: matrix of index i. -j: matrix of index j. -d: matrix of index d. (Use to mark delimitation for each channel during multi-dimensional arrays indexing). """ # get input size m, n_C, n_H, n_W = X_shape # get output size out_h = int((n_H + 2 * pad - HF) / stride) + 1 out_w = int((n_W + 2 * pad - WF) / stride) + 1 # ----Compute matrix of index i---- # Level 1 vector. level1 = np.repeat(np.arange(HF), WF) # Duplicate for the other channels. level1 = np.tile(level1, n_C) # Create a vector with an increase by 1 at each level. everyLevels = stride * np.repeat(np.arange(out_h), out_w) # Create matrix of index i at every levels for each channel. i = level1.reshape(-1, 1) + everyLevels.reshape(1, -1) # ----Compute matrix of index j---- # Slide 1 vector. slide1 = np.tile(np.arange(WF), HF) # Duplicate for the other channels. slide1 = np.tile(slide1, n_C) # Create a vector with an increase by 1 at each slide. everySlides = stride * np.tile(np.arange(out_w), out_h) # Create matrix of index j at every slides for each channel. j = slide1.reshape(-1, 1) + everySlides.reshape(1, -1) # ----Compute matrix of index d---- # This is to mark delimitation for each channel # during multi-dimensional arrays indexing. d = np.repeat(np.arange(n_C), HF * WF).reshape(-1, 1) return i, j, d def im2col(X, HF, WF, stride, pad): """ Transforms our input image into a matrix. Parameters: - X: input image. - HF: filter height. - WF: filter width. - stride: stride value. - pad: padding value. Returns: -cols: output matrix. """ # Padding X_padded = np.pad(X, ((0,0), (0,0), (pad, pad), (pad, pad)), mode='constant') i, j, d = get_indices(X.shape, HF, WF, stride, pad) # Multi-dimensional arrays indexing. cols = X_padded[:, d, i, j] cols = np.concatenate(cols, axis=-1) return cols def forward(self, X): """ Performs a forward convolution. Parameters: - X : Last conv layer of shape (m, n_C_prev, n_H_prev, n_W_prev). Returns: - out: previous layer convolved. """ m, n_C_prev, n_H_prev, n_W_prev = X.shape n_C = self.n_F n_H = int((n_H_prev + 2 * self.p - self.f)/ self.s) + 1 n_W = int((n_W_prev + 2 * self.p - self.f)/ self.s) + 1 X_col = im2col(X, self.f, self.f, self.s, self.p) w_col = self.W['val'].reshape((self.n_F, -1)) b_col = self.b['val'].reshape(-1, 1) # Perform matrix multiplication. out = w_col @ X_col + b_col # Reshape back matrix to image. out = np.array(np.hsplit(out, m)).reshape((m, n_C, n_H, n_W)) self.cache = X, X_col, w_col return out  ## 2) Pooling layer - We can make the average pooling operation faster by using **im2col** method. - ==Be aware that the np.reshape() method doesn't return the expected result here (elements in wrong order). A little bit of numpy gymnastic solves the problem.== <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/1-pool.png"> </div> --- Here is the implementation code: python= def forward(self, X): """ Apply average pooling. Parameters: - X: Output of activation function. Returns: - A_pool: X after average pooling layer. """ self.cache = X m, n_C_prev, n_H_prev, n_W_prev = X.shape n_C = n_C_prev n_H = int((n_H_prev + 2 * self.p - self.f)/ self.s) + 1 n_W = int((n_W_prev + 2 * self.p - self.f)/ self.s) + 1 X_col = im2col(X, self.f, self.f, self.s, self.p) X_col = X_col.reshape(n_C, X_col.shape[0]//n_C, -1) A_pool = np.mean(X_col, axis=1) # Reshape A_pool properly. A_pool = np.array(np.hsplit(A_pool, m)) A_pool = A_pool.reshape(m, n_C, n_H, n_W) return A_pool  # II) Backward propagation :::warning - This part will be tougher than the previous one. - However, if you have read the <a href="https://hackmd.io/@bouteille/ByusmjZc8" style="color:red">previous post</a> about the naive implementation of Convolutional Neural network using Numpy, it should be fine. - Along the way, you will often encounter a **"Be aware"** sentence about reshaping. I strongly advise you to run and play with unit_tests.py to understand why these numpy gymnastics were required. ::: ## 1) Convolutional layer :::info **Reminder:** - We performed a convolution between (1,3,4,4) input image and kernels of shape (2,3,2,2) which output an (2,3,3) image. - During the backward pass, the (2,3,3) image contains the error/gradient (**"dout"**) which needs to be back-propagated to the: - (1,3,4,4) input image (layer). - (2,3,2,2) kernels. ::: ## ⋆ Layer gradient: Intuition - The formula to compute the layer gradient is: $$\boxed{\frac{\partial L}{\partial I} = Conv(K, \frac{\partial L}{\partial O})}$$ - $\frac{\partial L}{\partial I}$: Input gradient. - $K$: Kernels. - $\frac{\partial L}{\partial O}$: Output gradient. - $Conv$: Convolution operation. - To do so, we will proceed as follow: - **A.** ==Reshape dout ($\frac{\partial L}{\partial O}$).== - **B.** ==Reshape kernels w into single matrix w_col.== - **C.** ==Perform matrix multiplication between reshaped dout and kernel.== - **D.** ==Reshape back to image (**col2im**).== - We are going to see how it works intuitively and then how to implement it using Numpy. ### A) <ins>Reshape dout</ins> - During backward propagation, the output of the forward convolution contains the error that needs to be back-propagated. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/15.png" width="80%"> </div> ### B) <ins>Reshape w into w_col</ins> <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/16.png"> </div> ### C) <ins>Perform matrix multiplication between reshaped dout and w_col</ins> - In order to perform to perform the matrix multiplication, we need to transpose w_col. - We will denoted the output as dX_col. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/17.gif"> </div> <br> - ==Notice that we are in fact, broadcasting the error in dout to each kernel as we did in the naive implementation.== <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/18.gif"> </div> <br> ### D) <ins>Reshape back to image (col2im)</ins> - ==Here, **col2im** is more than a simple backward operation of im2col. Indeed, we have to take care of cases where errors will overlap with others.== - As we can see in the previous gif, the (14,14,6) image has overlapping window. We need to reproduce the same effect ! <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/19.gif"> </div> <br> ## ⋆ Layer gradient: Implementation - The most difficult part of **col2im** is to reshape our matrix back to an image because it requires us to take care of the overlapping gradient. - An efficient and elegant way to do so is to use the [np.add.at](https://numpy.org/doc/stable/reference/generated/numpy.ufunc.at.html) method from Numpy. Here is a short example of how it works: python= >>> indices = [ [0,4,1], # rows. [3,2,4] # columns. ] >>> X = np.zeros((5,6)) >>> np.add.at(X, indices, 1) >>> X array([[0, 0, 0, 1, 0, 0], [0, 0, 0, 0, 1, 0], [0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0], [0, 0, 1, 0, 0, 0]])  - We will proceed as follow: - Create a matrix filled with 0 of the same shape as input image (add padding if needed). - X_padded: (1,3,4,4) with pad=0. - Use **get_indices()** which returns index matrices, necessary to transform our input image into a matrix. - i: (12,9) - j: (12,9) - d: (12,1) - Retrieve dX_col batch dimension by splitting it N (number of images) times. For example, if you have N images, then: - dX_col: (12, 9) => (N, 12, 9) - ==Be aware that the np.reshape() method doesn't return the expected result here (elements in wrong order). A little bit of numpy gymnastic solves the problem.== - Use i,j,d matrices as argument in np.add.at to reshape our matrix back to input image. - Refer to step ==[D) Reshape back to image (col2im)](#D-Reshape-back-to-image-col2im)== for np.add.at method visualization. - Remove padding from new image if needed. ## ○ Kernel gradient: Intuition - The formula to compute the kernel gradient is: $$\boxed{\frac{\partial L}{\partial K} = Conv(I, \frac{\partial L}{\partial O})}$$ - $\frac{\partial L}{\partial K}$: Kernels gradient. - $I$: Input image. - $\frac{\partial L}{\partial O}$: Output gradient. - $Conv$: Convolution operation. - To do so, we will: - **A.** ==Reshape dout ($\frac{\partial L}{\partial O}$).== - **B.** ==Apply **im2col** on X to get X_col.== - **C.** ==Perform matrix multiplication between reshaped dout and X_col to get dw_col.== - **D.** ==Reshape dw_col back to dw.== - We are going to see how it works intuitively and then how to implement it using Numpy. ### A) <ins>Reshape dout</ins> - ==Be aware that the np.reshape() method doesn't return the expect result here (elements in wrong order). A little bit of numpy gymnastic solves the problem.== <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/20.png" width="80%"> </div> ### B) <ins>Apply im2col on X to get X_col</ins> <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/21.gif"> </div> ### C) <ins>Perform matrix multiplication between reshaped dout and X_col to get dw_col</ins> - In order to perform to perform the matrix multiplication, we need to transpose X_col. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/22.png"> </div> <br> - ==Notice that we are in fact, broadcasting the error in dout to to each “slide” we did during the naive implementation forward propagation over the input==. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/23.gif"> </div> ### D) <ins>Reshape dw_col back to dw</ins> - We simply need to reshape dw_col back to its original kernel shape. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/24.png" width="80%"> </div> ## ○ Kernel gradient: Implementation - Nothing fancy here. --- Here is the code to implement the layer and kernel gradient. python= def col2im(dX_col, X_shape, HF, WF, stride, pad): """ Transform our matrix back to the input image. Parameters: - dX_col: matrix with error. - X_shape: input image shape. - HF: filter height. - WF: filter width. - stride: stride value. - pad: padding value. Returns: -x_padded: input image with error. """ # Get input size N, D, H, W = X_shape # Add padding if needed. H_padded, W_padded = H + 2 * pad, W + 2 * pad X_padded = np.zeros((N, D, H_padded, W_padded)) # Index matrices, necessary to transform our input image into a matrix. i, j, d = get_indices(X_shape, HF, WF, stride, pad) # Retrieve batch dimension by spliting dX_col N times: (X, Y) => (N, X, Y) dX_col_reshaped = np.array(np.hsplit(dX_col, N)) # Reshape our matrix back to image. # slice(None) is used to produce the [::] effect which means "for every elements". np.add.at(X_padded, (slice(None), d, i, j), dX_col_reshaped) # Remove padding from new image if needed. if pad == 0: return X_padded elif type(pad) is int: return X_padded[pad:-pad, pad:-pad, :, :] def backward(self, dout): """ Distributes error from previous layer to convolutional layer and compute error for the current convolutional layer. Parameters: - dout: error from previous layer. Returns: - dX: error of the current convolutional layer. - self.W['grad']: weights gradient. - self.b['grad']: bias gradient. """ X, X_col, w_col = self.cache m, _, _, _ = X.shape # Compute bias gradient. self.b['grad'] = np.sum(dout, axis=(0,2,3)) # Reshape dout properly. dout = dout.reshape(dout.shape[0] * dout.shape[1], dout.shape[2] * dout.shape[3]) dout = np.array(np.vsplit(dout, m)) dout = np.concatenate(dout, axis=-1) # Perform matrix multiplication between reshaped dout and w_col to get dX_col. dX_col = w_col.T @ dout # Perform matrix multiplication between reshaped dout and X_col to get dW_col. dw_col = dout @ X_col.T # Reshape back to image (col2im). dX = col2im(dX_col, X.shape, self.f, self.f, self.s, self.p) # Reshape dw_col into dw. self.W['grad'] = dw_col.reshape((dw_col.shape[0], self.n_C, self.f, self.f)) return dX, self.W['grad'], self.b['grad']  ## 2) Pooling layer - We first have to reshape our filters and divide by the filter size. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/25.png" width="80%"> </div> <br/> - We then repeat each element "filter size" time. <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/26.png" width="80%"> </div> <br/> - Finally, we apply **col2im**. - ==Be aware that the np.reshape() method doesn't return the expected result here (elements in wrong order). A little bit of numpy gymnastic solves the problem.== <div style="text-align:center"> <img src="https://raw.githubusercontent.com/valoxe/image-storage-1/master/blog-deep-learning/cnnumpy-fast/27.png" width="80%"> </div> --- Here is the implementation code: python= def backward(self, dout): """ Distributes error through pooling layer. Parameters: - dout: Previous layer with the error. Returns: - dX: Conv layer updated with error. """ X = self.cache m, n_C_prev, n_H_prev, n_W_prev = X.shape n_C = n_C_prev n_H = int((n_H_prev + 2 * self.p - self.f)/ self.s) + 1 n_W = int((n_W_prev + 2 * self.p - self.f)/ self.s) + 1 dout_flatten = dout.reshape(n_C, -1) / (self.f * self.f) dX_col = np.repeat(dout_flatten, self.f*self.f, axis=0) dX = col2im(dX_col, X.shape, self.f, self.f, self.s, self.p) # Reshape dX properly. dX = dX.reshape(m, -1) dX = np.array(np.hsplit(dX, n_C_prev)) dX = dX.reshape(m, n_C_prev, n_H_prev, n_W_prev) return dX  # III) Performance of fast implementation - The [naive implementation](https://github.com/3outeille/CNNumpy/tree/master/src/slow) takes around **4 hours for 1 epoch** where the [fast implementation](https://github.com/3outeille/CNNumpy/tree/master/src/fast) takes only **6 min for 1 epoch**. - For your information, **with the same architecture using Pytorch**, it will take around **1 min for 1 epoch**.
