# 架設叢集兩三事
## Hadoop 說明：
請參閱 https://hackmd.io/@JeffWen/HADOOP
* Hadoop三種模式:
1. 單機模式(Standalone Mode):
* 這種模式下不會啟動任何背景Java程式，此模式適合開發測試及除錯。
2. 偽分佈式模式(Pseudo-Distributed Mode)
- Hadoop中的背景Java程式均運行於本機節點，可以模擬小規模的叢集，[架設步驟請參閱](https://hackmd.io/@JeffWen/bdsevm)。
3. 完全分佈式模式(Fully-Distributed Mode)
- Hadoop中的背景Java程式運行數個主機上。
|屬性| 本機模式 | 偽分佈式模式 | 完全分佈式模式 |
|:---:|:--------:|:--------:|:--------:|
|fs.defaultFS| file:/// | hdfs:/// | hdfs:/// |
|dfs.replication|N/A|1|3|
|mapreduce .framework.name|N/A|yarn|yarn|
|yarn.resourcemanager.hostname|N/A|localhost|resourcemanager|
|yarn.nodemanager.auxervices|N/A|mapreduce_shuffle|mapreduce_shuffle|
### <Big>綱目</Big>
:::warning
**1. [Hadoop叢集基礎架設](#base)
2. [Spark及Jupyter應用程式安裝](#spark)
3. [叢集高可用性 HA(high availability)架設](#ha)
4. [一般叢集開(關)機程序](#normal)
5. [HA叢集開(關)機程序](#HA)
6. [Hadoop懶人腳本](#shell)
7. [SparkR架設，請參閱](https://hackmd.io/@JeffWen/sparkR)**
:::
<h3 id="base">Hadoop叢集基礎架設</h3>
0. 要準備的事項
1. DHCP伺服器找出沒有使用的子網路段
取子網路段30-34來充當5台電腦ip
:information_source: [DHCP科普請參考](http://linux.vbird.org/linux_server/0340dhcp.php)
2. 設定Windows 的host 名單
:information_source:[hosts科普請參考](https://zh.wikipedia.org/wiki/Hosts%E6%96%87%E4%BB%B6)
3. 擁有一台Ubuntu 18.04 server
請參考[Ubuntu 18.04 LTS Server 安裝不求人~~](https://hackmd.io/@JeffWen/ByVQYR2M8)
4. 資源配置
cpu:4
ram:8G
1台nna
1台rma
3台worker
---
1. 停用IPv6(**管理者身份**)
1. 檢查一下網路跟監聽的狀態(切換管理者)
```bash=
ip addr show
lsof -nPi
```
2. 修改開機設定檔
```bash
nano /etc/default/grub
```
3. 更新開機設定檔
```bash
update-grub # update-grub2
```
4. 重新開機
```bash
reboot
```
5. 檢查一下IPv6是否已經停用了
```bash=
ip addr show
lsof -nPi
```
---
2. 安裝pip(**管理者身份**)
1. 安裝python開發工具箱
```bash=
sudo apt update
sudo apt install python3-dev
```
2. 安裝pip
```bash=
#取得最新版pip腳本
wget https://bootstrap.pypa.io/get-pip.py
python3 get-pip.py
```
---
3. 建立hadoop帳號(**管理者身份**)
1.hadoop帳號
```bash
sudo adduser hadoop
```
2. 檢查是否已經創立
```bash=
grep 'hadoop' /etc/passwd
grep 'hadoop' /etc/group
grep 'hadoop' /etc/shadow
ls -l /home
```
4. 安裝OpenJDK8(**管理者身份**)
1. 更新倉庫清單
```bash
apt update
```
2. 安裝openjdk
```bash
apt install openjdk-8-jdk
```
3. 確認jdk及jre版本
```bash=
java -version
javac -version
```
4. 建立openjdk環境變數腳本
```bash
nano /etc/profile.d/jdk.sh
```
5. 編輯openjdk環境變數
```bash
export JAVA_HOME='/usr/lib/jvm/java-8-openjdk-amd64'
```
6. 重新載入設定檔，並檢查設定是否正確
```bash
source /etc/profile.d/jdk.sh # . /etc/profile.d/jdk.sh
```
5. 建立無密碼login(**Hadoop身份**)
1. 切換hadoop帳號
```bash
su - hadoop
```
3. 打造ssh公鑰及私鑰
```bash
ssh-keygen -t rsa
```
4. 將打造好的公鑰複製一份給hadoop
```bash
ssh-copy-id hadoop@localhost
```
5. 測試一下無密碼登入(不用輸入密碼代表成功了)
```bash
ssh hadoop@localhost
```
:warning:**要馬上exit退出來!!!**
~~6. 將自己的公鑰傳給其他人(自己電腦玩可以省略這一步)~~
:warning:**此方法並非正規作法，會提供寫入權限**
```bash=
ssh-copy-id hadoop@192.168.XX.XXX
ssh-copy-id hadoop@192.168.XX.XXX
ssh-copy-id hadoop@192.168.XX.XXX
```
---
6. 建立Linux hotsts名單(**管理者身份**)
```bash=
nano /etc/hosts
```
---
7. 下載及安裝hadoop(**管理者身份**)
1. 下載
```bash=
cd
wget http://ftp.tc.edu.tw/pub/Apache/hadoop/common/hadoop-3.2.1/hadoop-3.2.1.tar.gz
```
:information_desk_person: 如果載點失效，請至[官網下載~~](https://spark.apache.org/downloads.html)
2. 解壓縮
```bash
tar -tvf hadoop-3.2.1.tar.gz #查看一下檔案內容
tar -xvf hadoop-3.2.1.tar.gz -C /usr/local
```
3. 更名
```bash
mv /usr/local/hadoop-3.2.1 /usr/local/hadoop
```
4. 改變資料夾及檔案擁有者
```bash
chown -R hadoop:hadoop /usr/local/hadoop
```
---
8. 設定hadoop使用者環境變數 (**Hadoop身份**)
1. 設定.bashrc
```bash
nano ~/.bashrc
```
```bash=
# Set HADOOP_HOME
export HADOOP_HOME=/usr/local/hadoop
# Set HADOOP_MAPRED_HOME
export HADOOP_MAPRED_HOME=${HADOOP_HOME}
# Add Hadoop bin and sbin directory to PATH
export PATH=$PATH:$HADOOP_HOME/bin:$HADOOP_HOME/sbin
```
2. 重新載入設定檔
```bash
source ~/.bashrc # . .bashrc
```
3. 查看環境變數
---
9. 更改 Hadoop運行程式時環境腳本(**Hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/hadoop-env.sh
```
```bash=
export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-amd64
export HADOOP_HOME=/usr/local/hadoop
export HADOOP_CONF_DIR=/usr/local/hadoop/etc/hadoop
```
---
10. 更改 Hadoop core-site.xml(**Hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/core-site.xml
```
```xml=
<property>
<name>hadoop.tmp.dir</name>
<value>/home/hadoop/data</value>
<description>Temporary Directory.</description>
</property>
<property>
<name>fs.defaultFS</name>
<value>hdfs://test30.example.org</value>
<description>Use HDFS as file storage engine</description>
</property>
```
:information_source: Hadoop 3.2.0版之後有檢查語法指令
```bash
hadoop conftest
```
---
11. 更改 Hadoop mapred-site.xml(**Hadoop身份**)
參考hortonworks配置
```bash
nano /usr/local/hadoop/etc/hadoop/mapred-site.xml
```
```xml=
<property>
<name>mapreduce.map.memory.mb</name>
<value>2048</value>
</property>
<property>
<name>mapreduce.map.java.opts</name>
<value>-Xmx1638m</value>
</property>
<property>
<name>mapreduce.reduce.memory.mb</name>
<value>4096</value>
</property>
<property>
<name>mapreduce.reduce.java.opts</name>
<value>-Xmx3276m</value>
</property>
<property>
<name>yarn.app.mapreduce.am.resource.mb</name>
<value>4096</value>
</property>
<property>
<name>yarn.app.mapreduce.am.command-opts</name>
<value>-Xmx3276m</value>
</property>
<property>
<name>mapreduce.task.io.sort.mb</name>
<value>819</value>
</property>
<property>
<name>mapreduce.framework.name</name>
<value>yarn</value>
</property>
<property>
<name>mapreduce.jobhistory.address</name>
<value>test32.example.org:10020</value>
</property>
<property>
<name>mapreduce.jobhistory.webapp.address</name>
<value>test32.example.org:19888</value>
</property>
```
---
12. 更改 Hadoop yarn-site.xml(**Hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/yarn-site.xml
```
```xml=
<property>
<name>yarn.nodemanager.aux-services</name>
<value>mapreduce_shuffle</value>
</property>
<property>
<name>yarn.nodemanager.env-whitelist</name>
<value>JAVA_HOME,HADOOP_COMMON_HOME,HADOOP_HDFS_HOME,HADOOP_CONF_DIR,CLASSPATH_PREPEND_DISTCACHE,HADOOP_YARN_HOME,HADOOP_MAPRED_HOME</value>
</property>
<property>
<name>yarn.scheduler.minimum-allocation-mb</name>
<value>2048</value>
</property>
<property>
<name>yarn.scheduler.maximum-allocation-mb</name>
<value>6144</value>
</property>
<property>
<name>yarn.nodemanager.resource.memory-mb</name>
<value>6144</value>
</property>
<property>
<name>yarn.nodemanager.resource.detect-hardware-capabilities</name>
<value>true</value>
</property>
<property>
<name>yarn.nodemanager.resource.cpu-vcores</name>
<value>3</value>
</property>
<property>
<name>yarn.resourcemanager.hostname</name>
<value>test31.example.org</value>
</property>
<property>
<name>yarn.resourcemanager.scheduler.class</name>
<value>org.apache.hadoop.yarn.server.resourcemanager.scheduler.fair.FairScheduler</value>
</property>
```
---
13. 更改Hadoop hdfs-site.xml(**Hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/hdfs-site.xml
```
```xml=
<property>
<name>dfs.permissions.superusergroup</name>
<value>hadoop</value>
<description>The name of the group of super-users. The value should be a single group name.</description>
</property>
```
---
14. 建立Hadoop worker檔(**管理者身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/workers
```
---
15. 複製電腦 (**管理者身份**)
* 使用前檢查事項:
* 停用IPv6
* 建立hadoop帳號
* 完成無密碼login
* 建立hosts檔
* 建立worker檔
* 安裝OpenSSH server
* OpenJDK8安裝並設定
* 下載hadoop並修改完環境變數及相關設定
* ***確認無誤再執行不然會多做很多事情...***
1. 複製資料夾並更改資料夾名稱
3. 更改UUID(與資料夾名稱一樣)
4. 開機時候選擇I Copied It(會自動建立新的MAC)
6. 編輯cloud.cfg設定檔
```bash
sudo nano /etc/cloud/cloud.cfg
```
4. 修改hostname
```bash
hostnamectl set-hostname <HOSTNAME> #HOSTNAME自行設定
```
5. 編輯50-cloud-init.yaml設定檔，修改網路IP
```bash
sudo nano /etc/netplan/50-cloud-init.yaml
```
6. 套用網路設定
```bash
sudo netplan apply
```
7. 重開機(有多少台電腦就重複做幾次...)
```bash
reboot
```
* 全部電腦開機
---
16. Namenode format(**hadoop身份**)
```bash
hdfs namenode -format #只有Namenode那一台
```
---
17. 啟動hdfs(**hadoop身份**)
```bash=
start-dfs.sh #只有Namenode那一台
```
http://test30.example.org:9870
---
18. 啟動yarn(**hadoop身份**)
```bash=
start-yarn.sh #只有Resourcemanager那一台
```
http://test31.example.org:8088/
---
19. 啟動History Server(**hadoop身份**)
```bash=
mapred --daemon start historyserver #只有History Server那一台
#mr-jobhistory-daemon.sh start historyserver (deprecated)
```
---
20. 跑個pi 測試一下mapreduce (**hadoop身份**)
```bash=
hadoop jar /usr/local/hadoop/share/hadoop/mapreduce/hadoop-mapreduce-examples-3.2.1.jar pi 30 100
```
會自動建立hadoop的目錄
<Big>恭喜你完成第一階段Hadoop基本架設~~~</Big>
---
<h3 id="spark">Spark及Jupyter應用程式安裝</h3>
0. 請先確認叢集均已啟動服務
**:information_source: 請參閱[一般叢集開(關)機程序](#normal)**
1. 下載及安裝Spark(**管理者身份**)
1. 下載
```bash=
cd
wget http://ftp.tc.edu.tw/pub/Apache/spark/spark-2.4.4/spark-2.4.4-bin-hadoop2.7.tgz
```
2. 解壓縮
```bash
tar -xvf spark-2.4.4-bin-hadoop2.7.tgz -C /usr/local
```
3. 更名
```bash
mv /usr/local/spark-2.4.4-bin-hadoop2.7 /usr/local/spark
```
4. 修改spark資料夾及檔案使用者
```bash
chown -R hadoop:hadoop /usr/local/spark
```
---
2. 修改Spark環境變數(**hadoop身份**)
1. 設定.bashrc
```bash
nano ~/.bashrc
```
2. 重新載入設定檔
```bash
source ~/.bashrc #( . .bashrc)
```
3. 查看環境變數
---
3. 更改 Spark運行程式時環境腳本(**hadoop身份**)
1. 複製並建立一份spark-env腳本
```bash
cp /usr/local/spark/conf/spark-env.sh.template /usr/local/spark/conf/spark-env.sh
```
2. 編輯spark-env腳本
```bash
nano /usr/local/spark/conf/spark-env.sh
```
---
4. 跑個pi 測試一下Spark(**hadoop身份**)
```bash=
cd $SPARK_HOME
./bin/spark-submit --class org.apache.spark.examples.SparkPi \
--master yarn \
--deploy-mode cluster \
--driver-memory 1g \
--executor-memory 1g \
--executor-cores 1 \
--num-executors 3 \
--queue default \
examples/jars/spark-examples*.jar \
100
```
---
* 明顯看出Spark 遠遠勝過 MapReduce (同樣跑pi 100次)
MapReduce花費3分11秒
Spark花費14秒
---
5. 停止Spark運行程式時都要上傳jar檔到hdfs方式(**hadoop身份**)
* *每次都要上傳那麼多檔案擾民...*
1. 在 hdfs 建立目錄放jar檔
```bash=
hdfs dfs -mkdir -p /user/spark/share/jars
hdfs dfs -put $SPARK_HOME/jars/* /user/spark/share/jars/
hdfs dfs -ls /user/spark/share/jars
```
2. 上傳jar檔到hdfs
```bash=
hdfs dfs -mkdir -p /user/spark/share/jars
hdfs dfs -put $SPARK_HOME/jars/* /user/spark/share/jars/
```
3. 確認jar檔都上傳
```bash
hdfs dfs -ls /user/spark/share/jars | wc -l
```
4. 編輯spark-defaults.conf 的hdfs路徑
```bash=
cp /usr/local/spark/conf/spark-defaults.conf.template /usr/local/spark/conf/spark-defaults.conf
nano /usr/local/spark/conf/spark-defaults.conf
```
5. 跑個pi 檢測一下
出現一堆的Not copying就代表成功了
)
時間減少1秒
---
6. 使用PySpark shell(**hadoop身份**)
1. 使用Spark的readme當範本測試一下
2. 開啟pyspark shell
```bash=
cd $SPARK_HOME
./bin/pyspark --master yarn --deploy-mode client --num-executors 1 --executor-cores 1
```
3. 運行程式看看
---
7. 安裝jupter 系列及pyspark 等套件(**管理者身份**)
1. 安裝pyspark 套件
```bash=
pip3 install pyspark
```
2. 安裝jupter 系列套件
```bash=
pip3 install jupyterlab
```
---
8. jupyter 系列遠端使用及產生密碼(**一般使用者身份**)
1. 創建jupyter設定檔
```bash
jupyter notebook --generate-config
```
2. 修改設定檔
```bash
nano .jupyter/jupyter_notebook_config.py
```
3. 將登入網域開成全域
```bash
c.NotebookApp.ip = '0.0.0.0'
```
4. 產生密碼
```bash
jupyter notebook password
```
5. 開啟筆記本或是Lab
```bash
jupyter notebook #jupyter lab
```
**就可以藉由瀏覽器登入**
*~~或是用手機登入打code...瘋掉拉~~*
<Big>恭喜你完成第二階段應用程式安裝~~~</Big>
---
<h3 id="ha">叢集高可用性 HA(high availability)架設</h3>
:::danger
HA並非必要，步驟稍微複雜些，如果電腦效能沒有那麼好請自行斟酌
:::
:warning: 準備事項:
1. 三台Worker電腦當作Journalnodes及ZooKeeper
2. 原本的NameNode電腦多新增一個ResourceManager Stantby
3. 原本的ResourceManager電腦多新增一個NameNode Stantby
---
0. 請先確認叢集均已停止服務
**:information_source: [HA叢集開(關)機程序](#HA)**
1. 新增hdfs-site.xml檔，並SCP到其他台電腦(**hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/hdfs-site.xml
```
```xml=
<property>
<name>dfs.nameservices</name>
<value>nncluster</value>
</property>
<property>
<name>dfs.ha.namenodes.nncluster</name>
<value>nn1,nn2</value>
</property>
<property>
<name>dfs.namenode.rpc-address.nncluster.nn1</name>
<value>test30.example.org:8020</value>
</property>
<property>
<name>dfs.namenode.http-address.nncluster.nn1</name>
<value>test30.example.org:9870</value>
</property>
<property>
<name>dfs.namenode.rpc-address.nncluster.nn2</name>
<value>test31.example.org:8020</value>
</property>
<property>
<name>dfs.namenode.http-address.nncluster.nn2</name>
<value>test31.example.org:9870</value>
</property>
<property>
<name>dfs.namenode.shared.edits.dir</name>
<value>qjournal://test32.example.org:8485;test33.example.org:8485;test34.example.org:8485/nncluster</value>
</property>
<property>
<name>dfs.journalnode.edits.dir</name>
<value>/home/hadoop/journalnode</value>
</property>
<property>
<name>dfs.ha.fencing.methods</name>
<value>shell(/bin/true)</value>
</property>
<property>
<name>dfs.client.failover.proxy.provider.nncluster</name>
<value>org.apache.hadoop.hdfs.server.namenode.ha.ConfiguredFailoverProxyProvider</value>
</property>
```
:information_source: SCP指令範例
```bash
scp /usr/local/hadoop/etc/hadoop/hdfs-site.xml hadoop@test31:/usr/local/hadoop/etc/hadoop
```
2. 更正core-site.xml檔，並SCP到其他台電腦(**hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/core-site.xml
```
```xml=
<property>
<name>fs.defaultFS</name>
<value>hdfs://nncluster</value>
</property>
```
3. 三台電腦(Journalnodes)建立journalnode資料夾(**hadoop身份**)
```bash
mkdir ~/journalnode
```
4. 啟動journalnode，並jps確認(**hadoop身份**)
```bash
hdfs --daemon start journalnode
```
5. active NameNode限定(**hadoop身份**)
```bash
hdfs namenode -initializeSharedEdits
```
:warning: **請確認有出現Sucessfully started new epoch 1**
:information_desk_person: *如果此叢集是全新未使用過的請先format一下!!!!!*
```bash
hdfs namenode -format
```
6. 啟動第一台NameNode(**hadoop身份**)
```bash
hdfs --daemon start namenode
```
7. 第二台NameNode複製metadata(**hadoop身份**)
```bash
hdfs namenode -bootstrapStandby
```
:warning: **請確認有出現has been successfully formatted**
8. 啟動第二台NameNode(**hadoop身份**)
```bash
hdfs --daemon start namenode
```
9. 停止全部NameNode再啟動(**hadoop身份**)
```bash=
stop-dfs.sh
start-dfs.sh
```
:information_desk_person: **兩台namenode及三台journal node均會一起停止及啟動**
10. 激活第一台NameNode，並檢查狀態(**hadoop身份**)
```bash=
hdfs haadmin -transitionToActive nn1
hdfs haadmin -getServiceState nn1
hdfs haadmin -getServiceState nn2
```
11. 啟動Yarn(**hadoop身份**)
```bash
start-yarn.sh
```
12. 啟動Job history server(**hadoop身份**)
```bash
mapred --daemon start historyserver
```
13. 切換一下active Namenode(**hadoop身份**)
```bash=
hdfs haadmin -transitionToStandby nn1
hdfs haadmin -getServiceState nn1
hdfs haadmin -getServiceState nn2
hdfs haadmin -transitionToActive nn2
hdfs haadmin -getServiceState nn2
```
14. 跑個PI測試一下新起Namenode能不能正常運作(**hadoop身份**)
```bash
hadoop jar /usr/local/hadoop/share/hadoop/mapreduce/hadoop-mapreduce-examples-3.2.1.jar pi 30 100
```
15. 下載ZooKeeper並安裝(三台Zookeeper電腦都要)(**管理者身份**)
1. 下載ZooKeeper
```bash
wget http://ftp.tc.edu.tw/pub/Apache/zookeeper/zookeeper-3.5.6/apache-zookeeper-3.5.6-bin.tar.gz
```
2. 解壓縮
```bash
tar -xvf apache-zookeeper-3.5.6-bin.tar.gz -C /usr/local
```
3. 更名
```bash
mv /usr/local/apache-zookeeper-3.5.6-bin /usr/local/zookeeper
```
4. 修改擁有者
```bash
chown -R hadoop:hadoop /usr/local/zookeeper
```
16. 複製zoo_sample.cfg並編輯zoo.cfg(可以SCP到另外兩台)(**hadoop身份**)
```bash=
cp /usr/local/zookeeper/conf/zoo_sample.cfg /usr/local/zookeeper/conf/zoo.cfg
nano /usr/local/zookeeper/conf/zoo.cfg
```
```bash=
dataDir=/usr/local/zookeeper/zoodata #修改
admin.serverPort=8010 #新增
server.1=test32.example.org:2888:3888 #新增
server.2=test33.example.org:2888:3888 #新增
server.3=test34.example.org:2888:3888 #新增
```
17. 修改zkEnv.sh檔(可以SCP到另外兩台)(**hadoop身份**)
```bash=
nano /usr/local/zookeeper/bin/zkEnv.sh
```
```bash=
#新增
ZOO_LOG_DIR="/usr/local/zookeeper/logs"
ZOO_LOG4J_PROP="INFO,ROLLINGFILE"
```
18. 建立存放LOG資料夾(**hadoop身份**)
```bash=
mkdir /usr/local/zookeeper/zoodata
echo "1" > /usr/local/zookeeper/zoodata/myid #第一台zookeeper做
echo "2" > /usr/local/zookeeper/zoodata/myid #第二台zookeeper做
echo "3" > /usr/local/zookeeper/zoodata/myid #第三台zookeeper做
```
:warning: myid請務必要與zoo.cfg設定一樣
19. 修改環境變數(**hadoop身份**)
1. 編輯.bashrc
```bash
nano ~/.bashrc
```
2. 新增環境變數
```bash=
export ZOOKEEPER_HOME=/usr/local/zookeeper
export PATH=$PATH:$ZOOKEEPER_HOME/bin
```
3. 載入環境變數
```bash
source ~/.bashrc # . ~/.bashrc
```
20. 啟動ZooKeeper(三台電腦均要啟動)
```bash=
zkServer.sh start
zkServer.sh status
jps
```
:information_desk_person: 只有一台啟動時候，查看狀態會說It is probably not running.代表目前沒有其他zookeeper溝通
21. 依序停止下列服務
```bash=
#停止Historyserver
mapred --daemon stop historyserver
#停止ResoureManager
stop-yarn.sh
#停止NameNode
stop-dfs.sh
```
22. 新增hdfs-site.xml，並SCP到其他台電腦(**hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/hdfs-site.xml
```
```xml=
<!--新增 -->
<property>
<name>dfs.ha.automatic-failover.enabled</name>
<value>true</value>
</property>
```
23. 新增core-site.xml，並SCP到其他台電腦(**hadoop身份**)
```bash
nano /usr/local/hadoop/etc/hadoop/core-site.xml
```
```xml=
<!--新增 -->
<property>
<name>ha.zookeeper.quorum</name>
<value>master1.example.org:2181,master2.example.org:2181,master3.example.org:2181</value>
</property>
```
24. NameNode限定(**hadoop身份**)
```bash
hdfs zkfc -formatZK
```
:information_desk_person: 請確認出現Successfully created /hadoop-ha/nncluster in ZK字樣
25. 啟動NameNode(NameNode限定)(**hadoop身份**)
```bash
start-dfs.sh
```
:information_desk_person:將會自動啟動DFSZKFailoverController服務
26. 測試NameNode故障自動轉移(NameNode限定)(**hadoop身份**)
```bash=
hdfs --daemon stop namenode
hdfs haadmin -getServiceState nn1
hdfs haadmin -getServiceState nn2
```
27. 新增及刪除yarn-site.xml，並SCP到其他台電腦(**hadoop身份**)
```xml=
<!--刪除property -->
<property>
<name>yarn.resourcemanager.hostname</name>
<value>test31.example.org</value>
</property>
<!--新增property -->
<property>
<name>yarn.resourcemanager.ha.enabled</name>
<value>true</value>
</property>
<property>
<name>yarn.resourcemanager.cluster-id</name>
<value>rmcluster</value>
</property>
<property>
<name>yarn.resourcemanager.ha.rm-ids</name>
<value>rm1,rm2</value>
</property>
<property>
<name>yarn.resourcemanager.hostname.rm1</name>
<value>test31.example.org</value>
</property>
<property>
<name>yarn.resourcemanager.hostname.rm2</name>
<value>test30.example.org</value>
</property>
<property>
<name>yarn.resourcemanager.webapp.address.rm1</name>
<value>test31.example.org:8088</value>
</property>
<property>
<name>yarn.resourcemanager.webapp.address.rm2</name>
<value>test30.example.org:8088</value>
</property>
<property>
<name>yarn.resourcemanager.recovery.enabled</name>
<value>true</value>
</property>
<property>
<name>yarn.resourcemanager.store.class</name>
<value>org.apache.hadoop.yarn.server.resourcemanager.recovery.ZKRMStateStore</value>
</property>
<property>
<name>yarn.resourcemanager.zk-address</name>
<value>test32.example.org:2181,test33.example.org:2181,test34.example.org:2181</value>
</property>
```
28. 依序啟動下列服務(**hadoop身份**)
```bash=
#啟動ResoureManager
start-yarn.sh
#啟動Historyserver
mapred --daemon start historyserver
```
29. 測試ResourceManager故障自動轉移(Resourcemanager限定)(**hadoop身份**)
```bash
yarn --daemon stop resourcemanager
yarn rmadmin -getServiceState rm1
yarn rmadmin -getServiceState rm2
```
30. 如果有修改Spark-defaults.conf運行程式載入Jar檔，請記得修訂
```bash
nano /usr/local/spark/conf/spark-defaults.conf
```
<Big>恭喜你完成最後一階段 高可用性HA(high availability)架設~~~</Big>
<h3 id="normal">一般叢集開(關)機程序</h3>
1. 基本叢集開機
```bash=
#NameNode啟動
start-dfs.sh
#ResourceManager啟動
start-yarn.sh
#Historyserver啟動
mapred --daemon start historyserver
```
2. 基本叢集關機
```bash=
#Historyserver停止
mapred --daemon stop historyserver
#ResourceManager停止
stop-yarn.sh
#NameNode停止
stop-dfs.sh
```
<h3 id="HA">HA叢集開(關)機程序</h3>
1. HA叢集開機
```bash=
#ZooKeeper啟動
zkServer.sh start
#NameNode啟動
start-dfs.sh
#ResourceManager啟動
start-yarn.sh
#Historyserver啟動
mapred --daemon start historyserver
```
2. HA叢集關機
```bash=
#Historyserver停止
mapred --daemon stop historyserver
#ResourceManager停止
stop-yarn.sh
#NameNode停止
stop-dfs.sh
#ZooKeeper停止
zkServer.sh stop
```
<h3 id="shell">Hadoop懶人腳本</h3>
0. [**Hadoop懶人腳本介紹**](https://github.com/JeffWen0105/wen/tree/master/iiiEduBdse/release/hadoop)
1. [叢集一鍵開機](https://github.com/JeffWen0105/wen/blob/master/iiiEduBdse/release/hadoop/hadoopStartBdse12)
2. [叢集一鍵關機](https://github.com/JeffWen0105/wen/blob/master/iiiEduBdse/release/hadoop/hadoopStopBdse12)
3. [叢集狀態檢查](https://github.com/JeffWen0105/wen/blob/master/iiiEduBdse/release/hadoop/nodecheckBdse12)
4. [叢集安全遠端複製](https://github.com/JeffWen0105/wen/blob/master/iiiEduBdse/release/hadoop/safeScpBdse12)
5. [叢集遠端複製](https://github.com/JeffWen0105/wen/blob/master/iiiEduBdse/release/hadoop/scpBdse12)
Sign in with Wallet
Connect another wallet
