# Arweave Protocol URI Scheme This document describes the the `ar://` URI scheme and how to combined them with a user configurable gateway host to be translated to `http://` URIs. These are then be used by the browser to initiate a HTTP request to retrieve data from the Arweave network. ## Content Requests From inception, the impetus for creating a URI scheme for Arweave data is increasing decentralization. By decoupling the content identifier, the transaction id (`txid`), from the location it is served - the gateway host. It allows users to configure their preferred gateway to retrieve the content. Thus eliminating the dependency on any one gateway to bridge between the browser and the Arweave network. To achieve this the `ar://` URI scheme takes an `ar://{txid}` URI and maps it to its equivalent location at a configuragle Arweave gateway host, creating an `http://` URI scheme for it `https://{gateway host}/{txid}`. ### Transaction Id Lookup The most direct way to retrieve data stored on the Arweave network is to use the transaction id (`txid`) of the transaction that posted the data. The following is an example of how that flow works today (in Chrome via ArConnect plugin). ![](https://i.imgur.com/bqx6oWT.jpg) #### User Input First, the user enters the following into the browsers address bar. :::info ar://o5PwDrHU4dVcNVm8OB2RLT8shCDhlyVrjWdGMSV01vo ::: #### Browser Redirect :::info https://arweave.net/o5PwDrHU4dVcNVm8OB2RLT8shCDhlyVrjWdGMSV01vo ::: The `ar://` formatted URI causes the browser to redirect to the equivalent location at the gateway (configurable in settings). `https://arweave.net` is the most commonly used gateway today. #### Gateway Redirect :::info https://uoj7advr2tq5kxbvlg6dqhmrfu7szbba4glsk24nm5ddcjlu235a.arweave.net/o5PwDrHU4dVcNVm8OB2RLT8shCDhlyVrjWdGMSV01vo ::: Upon receiving a HTTP request for data at a specific `transactionId` the gateway responds with a HTTP redirect response, providing the requested content but serving it under a deterministically generated subdomain. This may seem like an unnecessary step but the justification for this step will become clear in the next use case. ## Permaweb Applications A compelling use case for a network that stores data permanently is the possibility of deploying permanent, serverless, single page applications (SPAs). These applications often rely on a more traditional (similar to `http://`) URI scheme. ![](https://i.imgur.com/ssHC6Yd.png) :::warning The above is an example URI, it is not intended to resolve to any SPA on Arweave. ::: ### Permaweb Requests ![](https://i.imgur.com/shQqNlx.jpg) ### By Transaction Id The `browser redirect` and `gateway redirect` work just as they did in the previous example, except this time the data being served is a static website or SPA. This is where the unique sub-domain on the `gateway redirect` comes into play. If every SPA loaded though the gateway was served at `arweave.net` with no subdomain, they would all share a single security sandbox. When a user retrieved one SPA that stored personal data in local storage, another SPA retrieved from the same gateway would be able to access the same local storage data and read it. This could lead to significant breaches in privacy and security. By creating a unique subdomain for each request the gateway can ensure a unique security sandbox for each asset stored on Arweave. ### By Transaction Id + Path + Query In this part of the example there's two ways a user might visit an article on the site. The first is by navigating to it by clicking on the article summary on the home page. The second is by following a direct link from an `ar://` formatted URI scheme. :::info ar://oLagmHm1-aUcMwYEAdprszz4WY9OMiNhkyYeFS1cA00/post?txid=kk_T_k8VAk6b_mAN7sWq1lBLSNaYxcyL7phtt4l1Nyo ::: | URI Element | Element Value | | -------- | -------- | | Scheme name | ar:// | | Transaction Id | oLagmHm1-aUcMwYEAdprszz4WY9OMiNhkyYeFS1cA00| | Path part | /post | | Query part | ?txid=kk_T_k8VAk6b_mAN7sWq1lBLSNaYxcyL7phtt4l1Nyo | #### Browser Redirect The `browser redirect` that occurs when provisioning this URI is similar to the basic [content requests](#Content-Requests) case. What changes is that the `Path part` and `Query part` are preserved. :::info https://arweave.net/oLagmHm1-aUcMwYEAdprszz4WY9OMiNhkyYeFS1cA00/post?txid=kk_T_k8VAk6b_mAN7sWq1lBLSNaYxcyL7phtt4l1Nyo ::: | URI Element | Element Value | | -------- | -------- | | Scheme name | https:// | | Host name | arweave.net | | Path part | /oLagmHm1-aUcMwYEAdprszz4WY9OMiNhkyYeFS1cA00/post| | Query part | ?txid=kk_T_k8VAk6b_mAN7sWq1lBLSNaYxcyL7phtt4l1Nyo | ## Emerging Standards ### Arweave Name System Arweave Name System (`ArNS`) is an emerging standard on Arweave that maps human readable names to transactionIds, much in the same way `DNS` maps human readable names to IP addresses on the Web, `ArNS` names are globally unique and allow the gateway to serve transaction data without requiring the transactionId be part of the URI. In order for `ArNS` names to interoperate with `DNS` names, `ArNS` names replace the deterministically generated sub-domain with a well known human readable name. Because this `ArNS` name is linked to a specific transactionId (`txid`) in the `ArNS` Smartweave contract state, it also eliminates the need to include the `txid` in the URI. The Arweave GraphQL guide is stored at the following `txid`. :::info iiO2AWChgG9yGWzw23IgxLetOOKr3eJiMfXPZrf6zzY ::: To retrieve it via the `arweave.net` gateway, we would navigate to the following gateway location. :::info https://arweave.net/iiO2AWChgG9yGWzw23IgxLetOOKr3eJiMfXPZrf6zzY ::: By registering an `ArNS` name with the `ArNS` SmartContract we can simplify the URL. In this case the `ArNS` name `gql-guide` was mapped to the transaction id `iiO2AWChgG9yGWzw23IgxLetOOKr3eJiMfXPZrf6zzY`, resulting in the following DNS name that points to the same transaction data. :::info https://gql-guide.arweave.dev ::: Important to notice here is the `arweave.dev` gateway is used for `ArNS` name lookups as opposed to the `arweave.net` gateway. This is because `ArNS` names are in their pilot phase. More can be read about the proposed Arweave Name System here [https://arns.arweave.dev/](https://arns.arweave.dev/). `ArNS` names represent an improvement in the accessibility of retrieving content on Arweave but they could improved it even further by being incorporated into the `ar://` URI scheme. As follows... :::info ar://gql-guide ::: ### ArNS Name Requests ![](https://i.imgur.com/2PaNQbv.png) In these examples, when the browser detects the presence of an `ArNS` name insted of a `txid` in the `ar://` scheme, it redirects to the `arweave.dev` gateway for processing. | URI | Action | Resulting URI | |-----|--------|--------| |ar://gql-guide|redirects to |https://gql-guide.arweave.dev| This is neccessary to support integration with the existing DNS system. Because this `gql-guide` sub-domain is guaranteed to be globally unique, it will maintain a unique security sandbox at this location. An important implementation detail here is if the user provides a path part or fragment along with the `ArNS` name in the `ar://` scheme it should be preserved when relocating to the `arwaeve.dev` gateway. | URI | Action | Resulting URI | |-----|--------|--------| |ar://gql-guide/#introduction|redirects to |https://gql-guide.arweave.dev/#introduction| This enables deep linking support for SPAs retrieved by their `ArNS` names. ## Future Directions An ideal implementation of the `ar://` URI scheme would support content retrieval by transaction id or `ArNS` name without requiring a redirect to a gateway to integrate with DNS. An example of a simple content request would resolve like the following. ![](https://i.imgur.com/l5vgfXl.jpg) An `ArNS` lookup would resolve seamlessly as well. ![](https://i.imgur.com/43p7SnD.png) ### URI Scheme Layering As it stands, browsers are designed to make HTTP requests which are explicitly described by the HTTP URI Scheme. The HTTP URI scheme includes hostnames which can be either an IP Address or a DNS name. Thus, both of these underlying protocols are implicitly part of the HTTP URI scheme and browser HTTP requests. ![](https://i.imgur.com/b0A1ljk.png) In order to support the `ar://` URI scheme without re-writing the entire browser stack from TCP/IP up, provisioning `ar://` URIs is done by transforming them into `https://` URIs. Which can then be used to make an HTTP request. ![](https://i.imgur.com/ealuP2y.png) In the above example the `ar://<txid>/path/?query#fragment` URI is mapped to a http URI using a gateway hostname so the browser can make an HTTP request to retrieve the data. Which gateway hostname to use is exposed in the browser settings, giving the user choice over what gateway to use. :::info Note that the `path`, `query`, and `fragment` components of the `ar://` URI scheme are preserved and transferred to the `https://` URI scheme. ::: ### ArNS Integration Much like how `DNS` is supported as an alternative to IP Addresses in the `http://` URI scheme, `ArNS` names should be supported as an alternative to transaction Ids in the `ar://` URI scheme. ![](https://i.imgur.com/jRwEaOj.png) The difference here is that `ArNS` is still a pilot program and will evolve over the the next year. As a result the best path forward is to support `ArNS` name mapping by having a browser plugin read the state of the `ArNS` contract. It would then map the `ArNS` name to a `txid` which could then be presented to the browser in the standard `ar://<txid>` scheme format (including `path`, `query`, and `fragment` parts). The browser would then do the usual `ar://` -> `https://` scheme mapping and make the HTTP request. The browser plugin could presumably use the same gateway host indicated in the browser settings to evaluate the state of the `ArNS` contract. ### Ideal Integration An idea `ar://` scheme integration would allow permaweb applications to encode `ar://` URIs in their HTML as links to remote resources. ```html <a href="ar://iiO2AWChgG9yGWzw23IgxLetOOKr3eJiMfXPZrf6zzY"> Arweave GraphQL Guide </a> ``` The browser would combine these schemes with the user configurable gateway information stored in the browser settings to make HTTP requests for the resources at the appropriate location. As of this writing, developers are forced to hard code an `https://` scheme gateway location for their resource paths. ```html <a href="https://arweave.net/iiO2AWChgG9yGWzw23IgxLetOOKr3eJiMfXPZrf6zzY"> Arweave GraphQL Guide </a> ``` This hard codes a centralized point of failure into the references which could be avoided with client configurable gateway settings and full support for `ar://` within HTML documents. ### Future Optimizations One way to optimize the performance of page loading under the `ar://` URI scheme would be to generate the deterministic subdomain on the client ahead of time, saving the gateway from having to redirect the client. As long as the gateway and client were using the same deterministic formula for generating the subdomain, the extra HTTP request for the subdomain redirect could be eliminated (improving performance of loading pages). Ultimately though, it would be better if the subdomain redirect was not necessary and there was some other way to ensure each asset served from the permaweb had its own security sandbox in the browser.
